Page 9: About
This manual shows you how to plan, configure, deploy, and manage a Mobility System wireless LAN (WLAN) using the 3Com Wireless LAN Switch Manager (3WXM) tool suite. Read this manual if you are a network administrator or a person responsible for managing a WLAN.
Page 10: Documentation
These notes provide information about the MSS software release, including new features and bug fixes. Wireless LAN Switch and Controller Quick Start Guide This guide provides instructions for performing basic setup of secure (802.1X) and guest (WebAAA™) access, for configuring a Mobility Domain for roaming, and for accessing a sample network plan in 3WXM for advanced configuration and management.
Page 11: Documentation Comments
Please include the following information when contacting us: Wireless LAN Switch Manager Reference Manual This manual shows you how to plan, configure, deploy, and manage a Mobility System wireless LAN (WLAN) using the 3Com Wireless LAN Switch Manager (3WXM). Wireless LAN Switch Manager User’s Guide...
Page 12 UIDE Example: Please note that we can only respond to comments and questions about 3Com product documentation at this e-mail address. Questions related to Technical Support or sales should be directed in the first instance to your network supplier. Wireless LAN Switch and Controller Configuration Guide...
Page 13: Getting Tarted
This chapter contains information about recommended system requirements you should meet for optimum 3WXM performance, installing 3WXM client and 3WXM Services software, and an introduction to using the 3WXM interface. Hardware Table 3 shows the minimum and recommended requirements to run the Requirements for 3WXM client on Windows and Linux platforms.
Page 14: Hardware Requirements For 3Wxm Services
1: G HAPTER ETTING TARTED Hardware Table 4 shows the minimum and recommended requirements to run the Requirements for 3WXM Services on Windows and Linux platforms. 3WXM Services Table 4 Hardware Requirements for Running 3WXM Services on Windows and Software 3WXM client and 3WXM Services are each supported on the following Requirements operating systems:...
Page 15: Preparing For Installation
After you have installed 3WXM, you will need to register your license and the serial number with 3Com in order to obtain an activation key. The base key along with its activation key enables you to manage up to 10 wireless LAN switches.
Page 16: Resource Allocation
1: G HAPTER ETTING TARTED Resource Allocation Table 5 contains general recommended guidelines for hardware requirements and memory allocation based on the number of radios and WX switches your server will support. A larger number of WX switches implies more connections and data processing, and consequently, more CPU is required.
Page 17: Installing 3Wxm
Installing 3WXM To install the 3Com Wireless Switch Manager, follow the instructions below for your operating system. Installing 3WXM on To install 3WXM on a Windows system: Windows Systems The 3WXM install program installs either just the 3WXM client, or both the 3WXM client and Services.
Page 18: Installing 3Wxm On Linux Systems
The installation begins. During the installation, the 3Com Wireless Switch Manager installation wizard minimizes. 6 When the installation is complete, maximize the 3Com Wireless Switch Manager installation wizard screen, and then press the Contents button. 7 Press the Exit button to close the wizard, or navigate to the other items on the CD.
Page 19 3WXM Services. If you plan to use the remote configuration option to configure new switches, you must use port 443 for 3WXM Services. When a switch requests its configuration from 3WXM Services, it sends the request to port 443.
Page 20: Start 3Wxm Services
To connect the client to Services: Clients to 3WXM Services 1 Select Start > Programs > 3Com > 3WXM > 3WXM. The 3WXM Services Connection wizard is displayed. 2 Enter the IP address or fully-qualified hostname of the machine on which the service is installed.
Page 21: Configure 3Wxm Services
Configure 3WXM You can change the properties of 3WXM Services. Services If a firewall is enabled on the host where you install 3WXM Services, 3WXM Services will not be able to communicate with 3WXM client or with WX switches unless the firewall is configured to allow through traffic for the SSL and SNMP ports (443 and 162 by default).
Page 22 HAPTER ETTING TARTED On each switch in the network plan, you must enable notifications and configure 3WXM Services as a notification target (trap receiver). 3WXM Services does not start listening for SNMP notifications from switches until you save the network plan.
Page 23: 3Wxm Access Control
5 Enter the account name and the password and click OK. 6 To remove an account, select the account and click Remove Account. 3WXM Interface This section contains the following topics: Wireless LAN Switch Manager Reference Manual Privilege Level Access Control Administrator...
Page 24: Display The Main Window
Content panel displays context-sensitive information about the device or configuration selected from the tree in the Organizer panel. From the Content panel, you can view 3Com devices and their status, verify 3Com device configurations in the network plan and in the network, and display event logs and Rogue detection results.
Page 25: Using The Toolbar And Menu Bar
You can use the Back and Forward buttons to cycle through your display selections. The menu bar (located above the toolbar) provides access to administrative options such as plan management and access to online help. For example, to open another network plan, select File > Switch Network Plan.
Page 26: Setting Preferences
1 Select the Monitor toolbar option. 2 In the Equipment section of the Organizer panel, select a Mobility Domain or a WX switch. 3 If not already selected, select Explore from the drop-down list in the Monitor tab. The topology view of the selected object is displayed.
Page 27: Getting Help
1 Select Help > Help to display HTML help about configuring and using 3WXM. 2 Select Help > Licensing to view product licensing information. 3 Select Help > Report Problem to report a problem to 3Com Technical Support. 4 Select Help > About 3WXM to display information about 3WXM and to display the Release Notes.
Page 28 1: G HAPTER ETTING TARTED...
Page 29 3WXM. Planning your wireless network is highly recommended because it not only helps you configure and deploy it, but also aids in scaling and monitoring your network. 3Com provides you with flexible tools to assist with network planning.
Page 30: Planning And
2: P HAPTER LANNING AND Which Services To What is a service? Provide? interface) that represents a set of options you configure and deploy on your wireless network. You configure services to support the different levels of network access you need to provide. For example, a service configured to support employee access will have different options configured to provide greater access to the network.
Page 31: Network Plan
Network Plan What is a network plan? use to design a wireless network. Why is this important? topology by creating a detailed and accurate network plan. You can start by creating a device-oriented (WX switches and MAPs) view of your network without any geographic information about your site—no floor dimensions, building material information, or RF obstacle information.
Page 32: Rf Auto-Tuning
Upload a WX switch configuration and deploy it. Enable the RF Auto-Tuning feature. This is a great way to install a WX switch and some MAPs, and observe how the network operates. The RF Auto-Tuning plan is best suited to networks containing fewer MAPs.
Page 33: Rf Planning
However, there are other requirements organizations should consider. 3Com recommends using the RF Auto-Tuning technique if you are installing MAPs without consideration to blanket coverage, throughput concerns, or the number of users for whom service will be provided. RF Auto-Tuning is ideal for small areas;...
Page 34 2: P HAPTER LANNING AND Use the RF Auto-Tuning with Modelling technique if you want to better monitor your wireless network in terms of buildings, floors, or coverage areas. You may only be able to locate inaccurate or incomplete building and floor plans (perhaps only a JPEG file), but with even a bit more geographic modelling of your site, you boost your ability to manage and visualize your network.
Page 35: Configuration
Do I want to better monitor my wireless network in terms of buildings, floors, or coverage areas? : To describe the main areas of the 3Com Network : To provide you with overview information about Wireless Service Wireless Configuration - Radio Profile...
Page 36: Wireless Configuration
2: P HAPTER LANNING AND This section contains information about: Wireless Wireless configuration focuses on the configuration tasks (radio Configuration configuration and AAA configuration) you do to deliver the virtual wireless services you want to provide on your network. You enable the MAPs to operate according to your planned RF coverage requirements.
Page 37 You must configure a radio profile to set attributes that you can apply to multiple radios. Rather than configuring each radio individually, you create a radio profile and apply it to multiple radios that you select. You can also create a radio profile as part of a policy and apply it to MAP access points on different WX switches.
Page 38: Aaa Security Configuration
Authentication is the method of determining whether a user is allowed access to your network. Users can be authenticated by a RADIUS server (pass-through) or by the WX switch local database (local). The WX switch can also assist the RADIUS server by performing the Extensible Authentication Protocol (EAP) processing for the server (offload).
Page 39 Figure 6 Authentication Flowchart for Network Users Client associates with 3Com radio or requests access from wired authentication port Client requests 802.1X rule that encrypted SSID? matches SSID? MAC rule that matches SSID? Use fallthru authentication last-resort? web? none? Client responds to 802.1X?
Page 40: System And Administration Configuration
These attributes are compared to the information contained in a local database or on a RADIUS server for a given user and the result is returned to the WX switch to determine the user’s actual capabilities and restrictions.
Page 41 Software (MSS) you want to run on the switch. Optionally, you can select an MSS image to download when you deploy changes to the WX. You also can specify if the switch is managed. A WX switch that is physically installed as well as configured can be managed. You can...
Page 42: Equipment Installation
To physically install a WX switch: Installation 1 Unpack and rack the WX switch in the wiring closet or data center location. 2 Plug the WX switch electrical cord into a power outlet. 3 Connect a network access cable from your existing network to one of the Ethernet ports on the switch (10/100 or Gigabit Ethernet, depending on the WX model and available interfaces on the network).
Page 43: Deployment
If you are indirectly connecting the WX to the switch, plug the other Deployment What is deployment? 3WXM network plan to your WX switch. Purpose of this section deployed to your network. Why is this important? deploying configurations to your WX.
Page 44: Network Status
Network Status 3WXM provides summary status on devices in the network at the Mobility Domain, switch or MAP level. View the summary status as the initial step in monitoring. Summary status displays the operational status of WX switches, MAPs, and their radios (whether they are up or down).
Page 45: Client Monitoring
RF neighborhood Statistics collected for the RF environment provides data on a per-channel basis. You can view noise levels, cyclic redundancy check (CRC) and PHY errors, packet retransmissions and percent utilization. Data collected for the RF neighborhood displays the neighboring radios. This information can be viewed as a list of radios heard by a particular radio, as well as a list of radios who can hear a particular radio.
Page 46: Rogue Detection
You can use RF countermeasures to deny service to or from a targeted rogue AP, and render them ineffective. Once a rogue AP is detected and reported, the closest 3Com MAP is assigned to perform RF countermeasures. By spoofing various 802.11 control messages, the MAP’s countermeasures disrupt association and authentication attempts...
Page 47: Verification
3WXM. Table 8 3WXM Reports Report Configuration Reports Inventory Report Mobility domain configuration Wireless Switch (WX) Configuration Site Survey Order Work Order Monitoring Reports Client Session Summary Client Session Details Management and Monitoring...
Page 48: Rf Plan Optimization
2: P HAPTER LANNING AND Table 8 3WXM Reports (continued) RF Plan What is optimization? Optimization to improve the accuracy of the model. Purpose of this section Why is this important? that determine the performance of your wireless network. Optimization of the RF model leads to a more successful RF plan.
Page 49 RF Plan Optimization Based on RF measurement data you gather in 3WXM to optimize the RF model of a floor, you can make configuration changes in the software to improve signal strength and coverage for groups or individuals, modify MAP locations, or add additional equipment to your wireless network if statistics indicate your network has outgrown the support provided by its current deployment of WX switches and MAPs.
Page 50 2: P 3WXM HAPTER LANNING AND ANAGING IRELESS ETWORK WITH...
Page 51: Configuring Wireless Services
This chapter contains examples to help you configure the following types of service sets: The configuration examples in this chapter take place on a WX switch already in the network plan. However, you also can preconfigure services in a policy and apply the policy to WX switches later.
Page 52: Configure Employee Access Services
“Create a 1 Tool bar option: select Radio Profile” Configuration. on page 56 2 Organizer panel: expand the WX switch. 3 Expand Wireless. 4 Click on Radio Profiles. 5 Select Radio Profile in the task list. Primary Parameters to Configure...
Page 53 On the RADIUS servers themselves, configure the AAA backed (not in 3WXM): Set up each WX switch as a RADIUS client. Define the 3Com vendor-specific attributes (VSAs) in the RADIUS server’s dictionary. Configure each user record with authorization rules (username and password).
Page 54: Step Summary
Click Finish. Configure the RADIUS server for 802.1X. Use the recommended EAP method, PEAP + MS-CHAPv2. Set up each WX switch as a RADIUS client. Define any desired 3Com vendor-specific attributes (VSAs). Primary Parameters to Configure From the Create Service Profile...
Page 55: Example: Configure Employee Access
3 Configure the RADIUS server in 3WXM: 4 Create a service profile for 802.1X service. 5 Set up a VLAN on the WX switches. Example: Configure The following detailed steps provide an example of how to configure Employee Access Employee services. You will: Configure each user record with either the VLAN-Name attribute or the RADIUS Tunnel-Private-Group-ID.
Page 56 To create a radio profile 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Radio Profiles. 4 In the Task List panel, select Radio Profile.
Page 57 5 Enter the name of the radio profile, then click Next at the bottom of the wizard. 6 If MAPs are already configured, select the radios to map to the radio profile, then click Move. 3WXM removes the radios from the radio profile they are in and places them in the new profile.
Page 58 To configure the RADIUS server in 3WXM 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch on which you are configuring the service. 3 Expand AAA, then select RADIUS.
Page 59 5 Type the name, IP address, and key, then click Next. 3WXM suggests the name of a server group to place the server in. The server group is required because AAA rules refer to server groups, not to individual servers. 6 Click Finish to save the server and create the server group.
Page 60 The vendor-specific attributes (VSAs) created by 3Com are embedded according to the procedure recommended in RFC 2865, with Vendor-ID set to 14525. Table 10 describes the 3Com VSAs, listed in order by vendor type number. Table 10 3Com VSAs...
Page 61 26, 43, 7 26, 43, 8 4 Configure each user record with authorization rules (username and password) and with either the Vlan-Name attribute (3Com VSA) or the RADIUS Tunnel-Private-Group-ID to assign users to VLANs. Other attributes are optional. Create a Service Profile for 802.1X Access A service profile contains the configuration for the service you want to offer, such as employee access, guest access, or VoWIP.
Page 62 3: C HAPTER ONFIGURING IRELESS ERVICES 5 Click Next. 6 Change the service profile name to Secure-802.1X-Employees, and use Employees as the SSID, as shown in the figure on the next page. 7 Click Next. Select WPA and deselect Dynamic WEP.
Page 63 8 Click Next. TKIP is already selected. 9 Click Next. Leave External RADIUS Server selected as the EAP Type. 10 Select the RADIUS server group in the Available RADIUS Server Groups list and click Add. 11 Click Next. Type vlan-mkt in the VLAN Name box. 12 Click Next.
Page 64 3: C HAPTER ONFIGURING IRELESS ERVICES 13 Click Finish. The new service profile appears in the Content panel. View the Service Profile’s Access Rules Every service profile requires access rules. The access rules specify the usernames or MAC addresses that are allowed to access the SSID. The service profile wizards automatically create access rules that match on all usernames (or that match on all MAC addresses, for VoWIP services).
Page 65 To view an 802.1X service profile’s access rules 1 Select the service profile in the Wireless Service Profiles table (located in the Content panel). A Setup group appears in the Task List panel. 2 In the Task List panel, select 802.1X Access. The Configure 802.1X Access wizard appears.
Page 66 VLAN configured. Optionally, each VLAN can have its own IP address. However, no two IP addresses on the switch can belong to the same IP subnet. User VLANs must be defined on at least one WX switch within the Mobility Domain.
Page 67 4 In the Task List panel, select VLAN. The Create VLAN wizard is displayed. 5 Enter vlan-mkt as the VLAN name and use the VLAN ID suggested by the wizard. 6 Click Next. Select the ports you want to use in the VLAN and click Add or Move.
Page 68: What's Next
3: C HAPTER ONFIGURING What’s Next? After you create Employee services, you can create additional services. For information about configuring additional services, refer to: After you have created additional services, you can create your RF environment, and deploy your configuration and enable monitoring. For information about creating your RF environment, refer to: For information about deploying your configuration and enabling monitoring of your network, see “Managing and Monitoring Your...
Page 69: Configure Guest Access Services
“Create a 1 Tool bar option: select Radio Profile” Configuration. on page 56 2 Organizer panel: expand the WX switch. 3 Expand Wireless. 4 Click Radio Profiles. 5 Select Radio Profile in the Task List. Configure Guest Access Services Primary Parameters to...
Page 70 IRELESS ERVICES Path 1 Tool bar option: select Configuration. 2 Organizer panel: expand the WX switch. 3 Expand AAA. 4 Click Local User Database. 5 Select User in the Task List. 1 Tool bar option: select Configuration. 2 Organizer panel: expand the WX switch.
Page 71: Step Summary
Step Summary The following list summarizes the fields selected or configuration items entered configure Guest access. 1 Create a radio profile. From the Radio Profile wizard, enter RadioProfile1 as the Name of the radio profile. Click Finish. 2 Configure users in the local database: From the Create Named User wizard, enter guest1 as username and guest1pass as the password.
Page 72 To create users 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand AAA, then select Local User Database. 4 In the Task List panel, select User.
Page 73 Leave the VLAN name unassigned. For Web Portal access, you specify the VLAN name when you configure the guest service profile. (See step 8 on page 77.) 6 Click Next. The wizard lists the authorization attributes you can configure for the user.
Page 74 3: C HAPTER ONFIGURING To create a user group and add users to it 1 In the Task List panel, select User Group. 2 Type a name for the group in the name box and click Next. The wizard lists the authorization attributes you can configure for the group.
Page 75 Create a Service Profile for Guest Access with Web Login To create a Web-Portal service profile 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Wireless Services. 4 In the Task List panel, select Web-Portal Service Profile.
Page 76 3: C HAPTER ONFIGURING IRELESS ERVICES 5 Click Next. 6 Change the service profile name to Web-Portal-Guests, and use the name Guests for the SSID.
Page 77 7 Select the SSID Type: Clear —Data is not encrypted Encrypted—Data is encrypted For this example, Clear is selected. 8 Click Next. Type or select the name of the VLAN you want to place your guests users in. For this example, use guest-vlan. Typing the VLAN name here does not actually configure the VLAN.
Page 78 (For a server group to be available in the wizard, the group must already be configured. See “Configure RADIUS Servers” on page 58.) For this example, LOCAL is selected. IRELESS ERVICES LOCAL—The switch’s local database RADIUS server group—group of external RADIUS servers...
Page 79 Configure Guest Access Services 11 Click Next. The wizard shows the user names configured in the local database. The users created in “To create users” on page 72 are listed.
Page 80 ONFIGURING Also listed is a user named web-portal-ssid, where ssid is the Web-Portal SSID name. This user is automatically created. The switch uses the web-portal-ssid username for users while they are in the portal and are being authenticated. After a user is authenticated, the username of the session changes to the user’s login name.
Page 81: Optional: Configure Mobility Profiles
When you apply the Mobility Profile, it guests have access only through specific areas of your WLAN—if they roam outside of a designated area supported by a WX switch or certain MAPs, they no longer have access to the Internet.
Page 82: What's Next
3: C HAPTER ONFIGURING 4 In the Task List panel, select Mobility Profile. The Create Mobility Profiles wizard appears. 5 In the Profile Name box, type the name of the Mobility Profile. The name can be up to 16 alphanumeric characters, and it cannot contain tabs.
Page 83: Configure Voice Over Wireless Ip Service
For information about deploying your configuration and enabling monitoring your network, refer to: Configure Voice Voice over Wireless IP (VoWIP) is a new technology, merging VoIP (Voice over Wireless IP over IP) with 802.11 wireless LANs to create a wireless telephone system. Service Organizations that add VoWIP to their wireless LANs can deploy and manage voice and data over a single wireless backbone, reserving some...
Page 84 Path “Create a Radio Profile” 1 Tool bar option: select on page 56 Configuration. 2 Organizer panel: expand the WX switch. 3 Expand Wireless. 4 Click Radio Profiles. 5 Select Radio Profile in the Task List. “Create a Service Profile 1 Tool bar option: select for Voice”...
Page 85: Step Summary
Step Summary The following list summarizes the fields selected or configuration items entered in the example that follows to configure VoWIP access: 1 Create a radio profile. From the Radio Profile wizard, enter RadioProfileVoic as the Name of the radio profile. Click Finish.
Page 86: Create A Radio Profile For Voice
(DTIM) interval to 3. To create a radio profile for voice service 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Radio Profiles. 4 In the Task List panel, select Radio Profile.
Page 87 Create a Service Profile for WMM VoWIP Devices 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Wireless Services. 4 In the Task List panel, select Voice Service Profile.
Page 88 3: C HAPTER ONFIGURING IRELESS ERVICES 9 Click Next. Select WPA and deselect Static WEP.
Page 89 Configure Voice over Wireless IP Service 10 Click Next. Leave TKIP enabled and click Next. 11 Click Next. Type a passphrase from 8 to 63 characters long in the Pre-shared Key box and click Generate.
Page 90 Create a Service Profile for SVP VoWIP Devices 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Wireless Services. 4 In the Task List panel, select Voice Service Profile.
Page 91 7 Leave SpectraLink selected in the Vendor drop-down list. 8 Click Next. Select Open Access and deselect MAC Access. 9 Click Next. Select WPA and deselect Static WEP. 10 Click Next. Leave TKIP enabled and click Next. 11 Click Next. Type a passphrase from 8 to 63 characters long in the Pre-shared Key box and click Generate.
Page 92 Create a Service Profile for Avaya VoWIP Devices 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Wireless Services. 4 In the Task List panel, select Voice Service Profile.
Page 93 Create a Service Profile for Vocera VoWIP Devices 1 Select Configuration on the toolbar. 2 In the Organizer panel, expand the WX switch. 3 Expand Wireless, then select Wireless Services. 4 In the Task List panel, select Voice Service Profile.
Page 94 (1 to 16 alphanumeric characters, with no spaces or tabs). The WX switch will authorize the user for that VLAN. For more information on VLANs, see “Viewing and Configuring VLANs”...
Page 95: What's Next
6 Click Next. Select the ports you want to use in the VLAN and click Add or Move. The ports appear in the Current Members list. To tag ports in the VLAN, select Tag and edit the tag value. (Tagging is required if you click Add, because the ports are then members of multiple VLANs.) 7 Click Next.
Page 96 3: C HAPTER ONFIGURING IRELESS ERVICES For information about deploying your configuration and enabling monitoring your network, refer to: “Managing and Monitoring Your Network” on page 155.
Page 97: Using Rf Auto -Tuning
RF planning or site surveys, and instead, relies on the AutoTune feature to set MAP channels and power settings. This is a great way to quickly install a WX switch and MAPs, and observe how the network operates. The RF Auto-Tuning technique is best suited to networks containing fewer MAPs.
Page 98: Place Your Equipment
1 Select the Configuration tool bar option. 2 In the Task List panel, select Upload Wireless Switch. 3 In the IP Address box, type the IP address for the WX switch. 4 In the Enable Password box, type the enable password for the WX switch.
Page 99: Create A Service Profile
“Which Services To Provide?” on page 30. To create a service profile 1 Select the Configuration tool bar option. 2 In the Organizer panel, click the plus sign next to the WX switch. 3 Click the plus sign next to Wireless. 4 Select Wireless Services.
Page 100: Create A Radio Profile And Map The Service Profile To It
Profile and Map the Service Profile to It 1 Select the Configuration tool bar option. 2 In the Organizer panel, click the plus sign next to the WX switch. 3 Click the plus sign next to Wireless. 4 Select Radio Profiles.
Page 101: Create Your Maps
1 Access the Create Direct-Connect AP wizard: a Select the Configuration tool bar option. b In the Organizer panel, click the plus sign next to the WX switch. c Click the plus sign next to Wireless. d Select Access Points.
Page 102 1 Access the Create Distributed AP wizard: a Select the Configuration tool bar option. b In the Organizer panel, click the plus sign next to the WX switch. c Click the plus sign next to Wireless. d Select Access Points.
Page 103 RSA key. If the MAP is already installed and operating, use the CLI command display dap status command to display the fingerprint. The fingerprint is used for secure communication between the WX switch and the MAP, and applies only to Distributed MAPs.
Page 104: Apply A Radio Profile To Each Radio
To apply a radio profile to a radio 1 Select the Configuration tool bar option. 2 In the Organizer panel, click the plus sign next to the WX switch. 3 Click the plus sign next to Wireless. 4 Select Radio Profiles.
Page 105: Using Rf Auto Uning With Modelling
What Is RF RF Auto-Tuning with modelling is a technique you can use to configure Auto-Tuning with and implement your network that builds on the RF Auto-Tuning method. Modelling? You will, as the name implies, still use RF Auto-Tuning (auto tuning) to adjust power and channel settings to provide RF signals to the coverage area for your users.
Page 106: Add Site Information
5: U RF A HAPTER SING Add Site By adding minimal information about your buildings and floors at your Information site, you support improved monitoring for your network. You can manually add building and floor information or you can import a floor. For information about importing a floor plan, see “Import a Floor Plan”...
Page 107 5 In the Starting Floor Level box, specify the floor number of the first floor in the building. To start with a subterranean floor, you can specify 0 or a negative floor number. 6 In the Skip Floor Levels box, specify floor numbers you want to skip. Skipping floors is useful when you want to model only certain floors in a building.
Page 108: Insert Rf Obstacles
5: U RF A HAPTER SING Insert RF Obstacles Add major RF obstacles that will affect the placement of your MAPs, such as solid walls, barriers, or elevator shafts. To add RF obstacles 1 Display the floor plan in the Content panel. 2 In the Task List panel, click Tools.
Page 109 Insert RF Obstacles A default attenuation factor is displayed for the object type, or, you can select an attenuation factor that you believe more closely matches the RF obstacle. 6 Click Finish. The RF obstacle is added to your floor layout.
Page 110: Create Your Rf Coverage Area
5 In the Name box, type the name of the wiring closet (1 to 60 characters, with no tabs). 6 Click a WX switch in the Available Devices box, then click the Add button to move it to the Current Devices box.
Page 111: Create Your Rf Coverage Area
Create Your RF To create your RF coverage area Coverage Area 1 Display the floor plan in the Content panel. 2 In the Task List panel, click Tools. 3 In the Create area under Coverage Area, click one of the icons and draw the RF coverage area you want to add to the floor by clicking and dragging the mouse.
Page 112 5: U RF A HAPTER SING 5 In the Name box for each technology, type a name for the coverage area (1 to 60 characters long, with no tabs). 6 In the Rate [Mb/s] list for each technology, select the average desired association rate for typical clients in this coverage area.
Page 113 9 To change the ceiling height, specify the new height in the Height of the Ceiling box. 10 To change the height where MAPs are mounted, specify the new mounting height in the MAP Placement Height box. 11 Click Next. The Default Device Settings page appears. Create Your RF Coverage Area...
Page 114 5: U RF A HAPTER SING 12 To change the default WX switch model, select the model from the WX Model list. 13 To change the default MAP model, select the model from the Default AP Model list. 14 To change the MAP connection type, select the type from the AP Connection Type list: 15 Click Next.
Page 115 17 To change the MAP connection type for the redundant connection, select Direct or Distributed from the MAP Connection Type list. 18 To change the number of redundant connections for the distributed connection type, type the number in the Redundancy Level box. For direct connections, the redundancy level is always 1.
Page 116 5: U RF A HAPTER SING 23 In the Station Oversubscription Ratio list, select the ratio for the average transmit behavior of the stations. The station oversubscription ratio is the ratio of active clients compared to total clients. For example, the ratio 5:1 indicates that, statistically, 20 percent of the clients are active at any given time.
Page 117 27 In the Active Handsets per AP list, specify the number of voice over IP phones that you want each MAP to handle. 28 In the Expected Handset Count list, specify the number of voice over IP phones you expect to be in the coverage area. 29 In the Handset Oversubscription Ratio list, select the ratio for the average transmit behavior of the voice over IP phones.
Page 118: Add Maps
3WXM creates it. 33 In the Wiring Closet list, select the wiring closet that contains the WX switch or switches to be connected to the shared MAPs. If the MAPs will be directly connected to WX switches, a wiring closet is required.
Page 119 5 Click the Associations tab to display area associations information for the coverage area. 6 In the Available Access Points box, select one or more available MAPs to use in the coverage area, then click Add to move the MAPs to the Current Access Points box.
Page 120: What's Next
5: U RF A HAPTER SING 9 Click on the MAP icon, then click on the location where you installed the MAP. The MAP icon moves from the Objects To Place panel to its location on the floor. What’s Next? This section provides cross references to information on the following tasks: UNING WITH...
Page 121: Using Rf Planning
For example, a network plan can represent a campus-wide network. 3Com recommends that you limit a network plan to a single campus or Mobility Domain. A network plan is also limited to one country, since a network plan only supports one common country code for the WX switches contained in it.
Page 122: Prepare The Floor Drawings
6: U RF P HAPTER SING LANNING Prepare the Floor Drawings If your floor drawings are contained in JPEG or GIF files, this step does not apply. Go directly to “Define Site Information” on page 123. If you plan to import AutoCAD DXF™ or AutoCAD DWG files into 3WXM, you should perform some “clean up”...
Page 123: Define Site Information
To create a network plan 1 Connect to a host running 3WXM Services. When you start 3WXM, the 3WXM main window and the 3WXM Services Connection dialog box appear. Define Site Information Wireless LAN Switch Manager Reference Manual.
Page 124 6: U RF P HAPTER SING LANNING 2 In the 3WXM Services Connection dialog box, enter the IP address of a host running 3WXM Services, optionally enter a user name and password, and click Next. If the 3WXM Service is installed on the same machine as the one you are using to run 3WXM, enter 127.0.0.1 as the IP address.
Page 125 To add site information 1 Select the RF Planning tool bar option. 2 In the Organizer panel, click the name of the network plan. 3 Select Create Site in the Task List panel. The Create Site wizard, a series of dialog boxes, prompts you for information about the new site. 4 In the Site Name box, type a name for the site (1 to 80 alphanumeric characters, with no spaces or tabs), and click Next.
Page 126 6: U RF P HAPTER SING LANNING To create a building 1 In the Organizer panel, click the site name. 2 Select Create Building in the Task List panel. The Create Building wizard prompts you for information about the new building. 3 In the Building Name box, type the name of the building (1 to 30 alphanumeric characters, with no spaces or tabs), and click Next.
Page 127 To add a floor to the building 1 In the Organizer panel, click the building name. 2 Select Create Floor in the Task List panel. The Create Floor wizard prompts you for information about the new floor. 3 In the Floor Name box, type the name of the floor (1 to 60 alphanumeric characters, with no spaces or tabs), and click Next.
Page 128: Import A Floor Plan
Import existing floor plans into 3WXM. The file can be in one of the AutoCAD DXF, AutoCAD DWG, JPEG, or GIF formats. 3Com recommends that you modify the AutoCAD files from AutoCAD to remove unnecessary objects and layers; then save them in .dxf format.
Page 129: Set The Scale
Set the Scale Set the scale on your floor plan to better define the distance between objects in your network. To set the scale 1 Display the floor plan in the Content panel. 2 Click a Draw a line on the floor plan over an object whose length you know; for example, a 3-foot door.
Page 130: Clean Layout
6: U RF P HAPTER SING LANNING Clean Layout Clean up your floor drawings further if unnecessary objects still remain after you your initial floor drawing cleanup. Note the following when cleaning up a drawing: For more information about cleaning up your floor plans, see “Prepare the Floor Drawings”...
Page 131 Define Site Information 3 Click Next. Cleanup progress is displayed at the bottom of the wizard. 4 You can display a Before Cleanup and After Cleanup view when cleanup is complete.
Page 132 6: U RF P HAPTER SING LANNING 5 When you are satisfied with the results, click Finish.
Page 133: Model Rf Obstacles
Model RF Obstacles When planning a 3Com network, you need to consider how the building layout and physical objects affect signal loss. Walls, windows, and doors absorb RF signals, and different building materials have different attenuation factors. You can model an RF obstacle on your floor plan and assign the obstacle type and attenuation factor, or you can assign an obstacle type and attenuation factor to objects in a DWG or DXF drawing.
Page 134: Import A Site Survey
RF obstacles can be obtained and incorporated into your plan. This guide contains post-deployment information about optimization on “Displaying the RF Coverage Area” on page 189. For pre-deployment information about optimization, see “Optimizing a Network Plan” in the Wireless LAN Switch Manager Reference Manual.
Page 135: Plan Rf Coverage
Plan RF Coverage How you plan the RF coverage for your network depends on whether you are planning for the widest coverage or are planning for capacity. There are other contributing factors. One group of users may be mobile and require high throughput performance (a higher bandwidth), while another group of users are more stationary and require less throughput.
Page 136: Create Coverage Areas
5 In the Name box, type the name of the wiring closet (1 to 60 characters, with no tabs). 6 Click a WX switch in the Available Devices box, then click the Add button to move it to the Current Devices box.
Page 137 When you draw a coverage area, it aligns to the grid to provide a whole number for width and height of the shape. To create a coverage area 1 Display the floor plan in the Content panel. 2 In the Task List panel, click Tools. 3 In the Create area under Coverage Area, click one of the icons and draw the RF coverage area you want to add to the floor by clicking and dragging the mouse.
Page 138 6: U RF P HAPTER SING LANNING 5 In the Name box for each technology, type a name for the coverage area (1 to 60 characters long, with no tabs). 6 In the Rate [Mb/s] list for each technology, select the average desired association rate for typical clients in this coverage area.
Page 139 9 To change the ceiling height, specify the new height in the Height of the Ceiling box. 10 To change the height where MAPs are mounted, specify the new mounting height in the MAP Placement Height box. 11 Click Next. The Default Device Settings page appears. Plan RF Coverage...
Page 140 RF P HAPTER SING LANNING 12 To change the default WX switch model, select the model from the WX Model list. 13 To change the default MAP model, select the model from the Default AP Model list. 14 To change the MAP connection type, select the type from the AP Connection Type list: 15 Click Next.
Page 141 17 To change the MAP connection type for the redundant connection, select Direct or Distributed from the MAP Connection Type list. 18 To change the number of redundant connections for the distributed connection type, type the number in the Redundancy Level box. 19 For direct connections, the redundancy level is always 1.
Page 142 6: U RF P HAPTER SING LANNING 24 In the Station Oversubscription Ratio list, select the ratio for the average transmit behavior of the stations. The station oversubscription ratio is the ratio of active clients compared to total clients. For example, the ratio 5:1 indicates that, statistically, 20 percent of the clients are active at any given time.
Page 143 28 In the Active Handsets per AP list, specify the number of voice over IP phones that you want each MAP to handle. 29 In the Expected Handset Count list, specify the number of voice over IP phones you expect to be in the coverage area. 30 In the Handset Oversubscription Ratio list, select the ratio for the average transmit behavior of the voice over IP phones.
Page 144: Compute And Place Maps
LANNING 34 In the Wiring Closet list, select the wiring closet that contains the WX switch or switches to be connected to the shared MAPs. If the MAPs will be directly connected to WX switches, a wiring closet is required. If all the MAPs in the coverage area will be indirectly connected to WX switches through the network, a wiring closet is not required.
Page 145 To determine the number and placement of MAPs 1 Display the floor plan in the Content panel. 2 In the Task List panel, click RF Planning. 3 Under RF Planning, click Compute and Place. The Compute and Place wizard appears. 4 To remove a coverage area from MAP placement and computation, clear the area’s Compute Layout box.
Page 146: Assign Channel Settings
6: U RF P HAPTER SING LANNING 7 Review the number of MAPs required for each coverage area, and the overriding criterion used (coverage or capacity). 8 Click Finish to apply the changes. Icons for the suggested MAP locations appear on the floor plan. Assign Channel After identifying the MAPs required for a coverage area, you need to Settings...
Page 147 To assign channels 1 Display the floor plan in the Content panel. 2 In the Task List panel, click RF Planning. 3 Under RF Planning, click Assign Channels. The Channel Assignment wizard appears, showing the current channel assignment constraints. 4 To change the starting floor for channel assignment, select the floor from the Begin On Floor List.
Page 148: Calculate Optimal Power
6: U RF P HAPTER SING LANNING 9 Review the results. The 802.11a channel assignments are listed on the 802.11a Radio(s) tab. The 802.11b/g channel assignments are listed on the 802.11b/g Radio(s) tab. 10 Click Finish to accept the channel assignments. The new channel assignments are reflected in the Coverage Areas panel.
Page 149 To calculate optimal power 1 In the Task List panel, click RF Planning. 2 Under RF Planning, click Compute Optimal Power. The Compute Power For wizard appears, showing a list of the areas you defined and the corresponding technology. 3 To optimize the AP count, select Optimize AP Count. This option checks for coverage overlaps and removes an MAP if neighboring MAPs provide enough coverage to make the MAP unnecessary.
Page 150: Display Coverage
6: U RF P HAPTER SING LANNING Display Coverage Looking at the RF coverage allows you to see if the entire area is adequately covered by the MAPs. You can move the MAPs and see how the coverage changes. To display the RF coverage for an area 1 Beside Show RF Coverage Using, select how you want to display the coverage: 2 Right-click on a coverage area and select Show RF Coverage.
Page 151: Generate A Work Order
Order planning. The work order provides all of the necessary information for the physical installation of the 3Com Mobility System. A work order shows where the MAPs should be installed, WX initial setup configuration information, and projected RSSI information that is useful when verifying the installation.
Page 152 6: U RF P HAPTER SING LANNING 4 Specify the work order options. 5 In the Language list, select English or German. The language you select is the language used when you next access this page. 6 To select the directory to which the work order report is saved, click Choose.
Page 153: Install The Equipment
After you print the work order from 3WXM, you can distribute it to your Equipment installers. The work order shows where to install the 3Com equipment. If you have specified third-party APs in the network plan, those will be considered in the work order, too.
Page 154 6: U RF P HAPTER SING LANNING...
Page 155: Managing And Monitoring Your Network
For detailed information about monitoring, see the chapter “Monitoring the Network” in the For detailed information about performing administrative tasks on a WX switch, see the chapter “Configuring WX System and Administrative Parameters” in the Deploy Your Any changes you make to your network in 3WXM are saved in the...
Page 156 (You can use the Verification tab to fix the errors.) If the deploy is successful, 3WXM also instructs the WX switch to save the changes in its configuration file.
Page 157: Perform Basic Administrative Tasks
CLI prompt and the banner message that appears at each session. HTTPS—By default, HTTPS is enabled. TCP port 443 is used for secure access by Web Management, the 3Com Web-based application for managing a WX switch. Telnet—By default, Telnet is disabled. You can enable Telnet for unencrypted access to the CLI.
Page 158 To manage services on a WX switch 1 Select the Configuration tool bar option. 2 In the Organizer panel, click the plus sign next to the WX switch. 3 Click the plus sign next to System. 4 Select Management Services.
Page 159: Distributing System Images
To use a new system image, you must reboot the WX. 3Com recommends that you use the Verification tab to resolve any configuration errors or warnings before you distribute system images. Before you can distribute an image, you must add it to the image repository.
Page 160: Saving Versions Of Network Plans
You can save multiple versions of a network plan. After deploying a Network Plans network plan to a WX switch, you can save a snapshot of the plan as a version. Create versions of the network plan on a regular basis and at every major baseline event for network configurations.
Page 161: Importing And Exporting Switch Configuration Files
Importing and Exporting Switch Configuration Files The import option enables you to create a WX switch in the network plan by importing configuration files in Extensible Markup Language (XML) format. You also can update the configuration of a switch that is already in the plan.
Page 162 8 Click Import. The status of the import process appears in the Status column. 9 Click Close to save the changes. 10 Enable 3WXM to manage the switch. (Select the switch in the Organizer panel, select Managed, then click Save.) To export a configuration 1 Select File >...
Page 163: Monitoring Examples
4 To overwrite previously exported configuration files, select Overwrite Existing Files. If you do not select this option, you cannot export a configuration file with the same name as an existing file in the output directory. You can rename the existing file or move the file to another directory. 5 To have 3WXM create a backup copy of a previous configuration file, select Copy Files Before Overwriting.
Page 164 7: M HAPTER ANAGING AND 4 View statistics over a period of time. Placing the user on the watch list allows 3WXM to gather long-term statistics. Find the User You can find a user or multiple users based on the following criteria: To find the user 1 Click on the Monitor option in the main 3WXM tool bar.
Page 165 4 Enter the type of search you want to perform, and select the scope for the search. 5 Click Next. The search results appear. Place User on Watch List If viewing the user’s current activity does not conclusively indicate the source of the problem, you can place the user on a watch list.
Page 166 7: M HAPTER ANAGING AND You can also add a user to the watch list by clicking the Client Sessions tab in the Client Monitor view, selecting the client, and clicking the icon on the toolbar. Locate the User You can display the user’s approximate location by doing the following: 1 Click on the Monitor option in the main 3WXM tool bar.
Page 167 Display User Activity You can display the event types displayed for the user. Disassociation events can occur, and users dropped from the network. These events can indicate the reason why access is barred or performance slow for the user. For example, typical authorization failures occur if the local database or RADIUS server fails to recognize a user.
Page 168 7: M HAPTER ANAGING AND Using this data, you can determine whether the user’s problem is interference due to low bandwidth (Unicast Bytes in). 3 Select the Trend: Session Stats tab to display Operational Rate, SNR, and RSSI statistics. Signal to Noise Ratio (SNR) statistics can help you determine whether the interference is being created by too much noise on a channel.
Page 169: Monitor A Group Of Users
A high number of Transmit Timeouts for either the Current MAP or Lifetime of the user can indicate interference problems. 5 Select the Location History tab to view where the user has been roaming. These statistics indicate whether interference problems are occurring in specific areas of the WLAN.
Page 170 2 Select the RF Trends view. 3 Expand the Equipment list in the Organizer panel, and select a radio. You can view trends for a WX switch or a MAP. 4 View the Client Failures count. A high count can indicate a problem with the radio.
Page 171: Monitor A Rogue
Monitor a Rogue MAP radios automatically scan the RF spectrum for other devices transmitting in the same spectrum. The RF scans discover other 3Com radios, as well as third-party, non-3Com transmitters. MSS considers the non-3Com transmitters to be potential rogues, and places them on a rogue list.
Page 172 7: M HAPTER ANAGING AND To locate a rogue 1 Click on the Rogue Detection option in the main 3WXM tool bar. The current rogue list is displayed. 2 View statistics on a single rogue. Select a rogue from the Filtered List, then select the Activity Log tab.
Page 173 To enable countermeasures 1 Click on the Configuration option in the main 3WXM tool bar. 2 In the Organizer panel, click the plus sign next to the WX switch. 3 Click the plus sign next to Wireless. Monitoring Examples...
Page 174 7: M HAPTER ANAGING AND 4 Select Radio Profiles. 5 In the Task List panel, click on Create Radio Profile. The Create Radio Profile wizard appears. 6 In the Name box, type the name of the radio profile (1 to 16 characters, with no spaces or tabs), and click Next.
Page 175 7 Select the MAP radios on which you want to enable countermeasures from the Available Members column, and click Move to move the radios to the Current Members column. 8 Click Next. The Radio Profile Service Selection page appears. 9 To map the radio profile to a service profile, select the service profile in the Available Service Profiles list and click Add.
Page 176 Countermeasures Mode pull-down list: A rogue is a device that is in the 3Com network but does not belong there. An interfering device is not part of the 3Com network but also is not a rogue.
Page 177 13 To disable active scanning for rogue devices, deselect Enable Active Scan. When active scan is enabled, radios send probe any requests (probe requests with a null SSID name), to solicit probe responses from other access points. Radios also passively scan by listening for beacons and probe responses.
Page 178 7: M HAPTER ANAGING AND ONITORING ETWORK...
Page 179: Optimizing A Network Plan
Optimizing your network is a post-deployment technique. You can optimize your WLAN by importing RF measurement data to correct RF attenuation obstacle information in your network plan. You optimize your network plan because: You have a reported coverage problem in your network You want to verify your network RF coverage The RF measurement data you use to optimize your network plan can originate from:...
Page 180: Using Rf Measurements From Maps
8: O HAPTER PTIMIZING A The following sections describe how to import RF measurements from your network, or how to import RF measurements from an Ekahau site survey. Using RF You can apply the RF measurements derived from the MAPs in your Measurements WLAN (which regularly monitors the RF environment) to your network from MAPs...
Page 181: Using Rf Measurements From An Ekahau Site Survey
Using RF RF measurements come from a site survey file generated by the Ekahau Measurements Site Survey tool. To perform a site survey: from an Ekahau Site Survey The chapter guides you through the tasks you need to do in 3WXM. For information about tasks you need to do in the Ekahau Site Survey tool, please refer to the ESS tool’s documentation.
Page 182: Generating An Ekahau Site Survey Work Order
8: O HAPTER PTIMIZING A Generating an The site survey order contains the locations and MAC addresses of the Ekahau Site Survey MAPs for use when conducting a site survey, and also provides a JPEG Work Order image of the floor. To generate a site survey order 1 Display the floor plan in the Content panel.
Page 183 Using RF Measurements from an Ekahau Site Survey 4 Select the scope for which you want generate a site survey order. You can specify the Network Plan, an individual site, an individual building, or an individual floor. 5 Select the language: English or German 6 To change the output directory for the report, click on the button next to output directory, navigate to the new directory, and click Select.
Page 184 8: O HAPTER PTIMIZING A ETWORK 10 Browse to the output directory and locate the JPEG file. Copy this file and import it into your Ekahau Site Survey tool. Proceed with your site survey.
Page 185: Importing Rf Measurements From The Ekahau Site Survey
Importing RF After you complete the site survey, you import the csv file containing the Measurements from RF measurements from the Ekahau Site Survey tool into your network the Ekahau Site plan. After you import your RF measurements, you optimize to correct Survey attenuation for obstacles on the floor.
Page 186 8: O HAPTER PTIMIZING A 8 Click Next. The import progress is displayed. When the import is done, check the Total valid RF measurements found line in the progress messages. ETWORK If the number is greater than 0, 3WXM successfully imported measurements.
Page 187: Optimizing The Rf Coverage Model
After you import your RF measurements, you correct the attenuation factors for the floor. Go to “Optimizing the RF Coverage Model” next for information about this topic. Optimizing the RF An attenuation library is a set of attenuation values for the RF obstacles Coverage Model on a floor.
Page 188 8: O HAPTER PTIMIZING A 4 Click Finish. You have optimized your RF coverage model with the new RF obstacle information. Now you can locate and fix coverage holes, or if necessary, replan your network. ETWORK The Total number of RF measurements that did not intersect any object line lists the number of measurements that did not experience attenuation due to an RF obstacle in the path between them.
Page 189: Locating And Fixing Coverage Holes
Locating and Fixing After you import RF measurements and rebuild the attenuation library, Coverage Holes you can look for coverage holes by displaying coverage. To locate coverage holes: Displaying the RF Display the RF coverage area to view the RF coverage based on the Coverage Area corrected attenuation data.
Page 190: Locking Down Maps
8: O HAPTER PTIMIZING A 6 On the toolbar, click the radio type (A, B, or G) for which you want to display coverage. Coverage for the selected scope(s) is displayed. This example shows 802.11a coverage, by transmit data rate, for the coverage area CoverA. Locking Down MAPs To prevent 3WXM from moving a MAP on your network plan that you do not want to be redistributed, lock the MAP down.
Page 191: Fixing A Coverage Hole
Add to move the MAPs to the Current Access Points box. 7 Click OK to close the dialog box. Locating and Fixing Coverage Holes Wireless LAN Switch and Guide. This guide contains instructions...
Page 192: What's Next
8: O HAPTER PTIMIZING A 8 In the Organizer panel, click on Objects to Place. A list of the MAPs you created is displayed in the panel. 9 Click on the MAP icon, then click on the location where you installed the MAP.
Page 193: Upport For
To take advantage of warranty and other service benefits, you must first Product to Gain register your product at: Service Benefits http://eSupport.3com.com/ 3Com eSupport services are based on accounts that are created or that you are authorized to access. Solve Problems 3Com offers the following support tool: Online...
Page 194: Purchase Extended Warranty And Professional Services
3Com as a separately ordered product. Separately orderable software releases and licenses are listed in the 3Com Price List and are available for purchase from your 3Com reseller.
Page 195: Telephone Technical Support And Repair
When you contact 3Com for assistance, please have the following information ready: To send a product directly to 3Com for repair, you must first obtain a return materials authorization number (RMA). Products sent to 3Com without authorization numbers clearly marked on the outside of the package will be returned to the sender unopened, at the sender’s...
Page 196 Return material authorization: warranty_repair@3com.com Contract requests: emea_contract@3com.com Latin America — Telephone Technical Support and Repair Antigua 1 800 988 2112 Argentina 0 810 444 3COM Aruba 1 800 998 2112 Bahamas 1 800 998 2112 Barbados 1 800 998 2112 Belize...
Page 197 Country Telephone Number US and Canada — Telephone Technical Support and Repair All locations: Network Jacks; Wired or Wireless Network Interface Cards: All other 3Com products: Contact Us Country Telephone Number 1 847-262-0070 1 800 876 3266...
Page 198 A: O PPENDIX BTAINING UPPORT FOR RODUCTS...
Page 199 About This Guide 9 text, About This Guide 10 deploy overview of 43 verifying 157 direct connect MAPs 101 directory of 3Com resources 195 distributed MAPs 101 creating 102 distributing system images 159 distributing WX software images 159 Ekahau Site Survey tool 179...
Page 200 NDEX event logging 46 exporting configurations 161 Express services contract 194 extended warranty options 194 fixing coverage holes 191 Guardian services contract 194 hardware requirements for installation 13, 14 HP OpenView 15 HTTPS, enabling 158 image files distributing 159 image repository adding image 159 deleting image 159 using 159...
Page 201 RF coverage model 187 RF measurements, from Ekahau Site Survey 181 RF measurements, from MAPs 180 product registration 193, 194 Professional Services from 3Com 194 purchasing license keys 194 purchasing software upgrades 194 radio profiles applying to each radio 104...
Page 202 NDEX sending products to 3Com for repair 195 server hardware allocation 16 service benefits 193, 195 service profiles configuring 61 configuring, RF Auto-Tuning 99 purpose of 36 services configuring employee access example 55 configuring, guest access 69 configuring, VoWIP 83...
Page 203 work orders generating 151 WX software images 159 WX switches available models 41 configuring management services 157 configuring, basic properties 41 configuring, boot information 42 configuring, connection information 42 configuring, VLANs on 66 deploying configurations 155 installing, equipment 42 uploading configuration 98 NDEX...
Page 204 NDEX...

This manual is also suitable for:

3crwx440095a 3crwx120695a 3crwxr10095a 3crwx220095a Wx4400 Wx1200 ... Show all

3Com Wireless LAN Controller WX2200 User Manual

About

1 Getting Tarted

2 Planning and

3 Configuring Wireless Services

4 Using Rf Auto -Tuning

5 Using Rf Auto Uning with Modelling

6 Using Rf Planning

7 Managing and Monitoring Your Network

8 Optimizing a Network Plan

Quick Links

Related Manuals for 3Com Wireless LAN Controller WX2200

Summary of Contents for 3Com Wireless LAN Controller WX2200

This manual is also suitable for:

Table of Contents
