Soft Switch: #61; Soft Switch: #62 - Konica Minolta BIZHUB 163 Service Manual

8. Soft Switch Set
8.6.63

SOFT SWITCH: #61

Bit
Designation
No.
8 Reserved
7 Reserved
6 Reserved
5 Reserved
4
3
2
Max. No. of rings
1
8.6.64

SOFT SWITCH: #62

Bit
Designation
No.
8 Reserved
7 Reserved
6 Reserved
5 Reserved
4 Reserved
3 Reserved
2 Reserved
1 Reserved
104
Function
Reserved
Reserved
Reserved
Reserved
No. of rings 1 2
Bit 4 0 0
Bit 3 0 0
Bit 2 0 0
Bit 1 0 1
No. of rings 9 10 11 12 13 14 15
Bit 4 1 1
Bit 3 0 0
Bit 2 0 0
Bit 1 0 1
Function
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Field Service Ver. 1.0 Apr. 2007
3 4 5 6 7 8
0 0 0 0 0 0
0 0 1 1 1 1
1 1 0 0 1 1
0 1 0 1 0 1
16
1 1 1 1 1 1
0 0 1 1 1 1
1 1 0 0 1 1
0 1 0 1 0 1
Initial
Setting
Bit HEX
0
0
0
0
0
1
1
1
F
1
Initial
Setting
Bit HEX
0
0
0
0
0
0
0
0
0
0
