Assembling an Adjustable Bracket for a Sun 72-inch Expansion Cabinet or
FIGURE 3-2
Sun Fire Expansion Cabinet
b. For Sun Rack 900 and other industry standard 19" racks or cabinets, position
the double-angled end (A) of the slotted piece (C) towards the front, with the
screws on the smooth piece (B) extending through the longer slot of the slotted
piece (
FIGURE 3-3
Assembling an Adjustable Bracket for a Sun Rack 900 or Standard 19-inch
FIGURE 3-3
Rack or Cabinet
4. Loosely secure the two parts of each bracket, tightening two of the M4 kep nuts
supplied in the bracket's ship kit over the screws.
As shown in
FIGURE 3-2
bracket that faces the rack's posts (C).
B
).
B
and , the nuts are attached from the side of the
FIGURE 3-3
Chapter 3 Installing the Sun StorEdge S1 Array
