Checking Back Panel Leds; System Power And System Summary Fault Leds; Figure 5-4 Back Panel Leds - Sun Microsystems StorEdge S1 Array Installation And Maintenance Manual

Note – Some servers reserve SCSI ID 6 for use by CD drives and IDs 0 and 1 for
internal drives. See "To Determine the Drive Bay's SCSI ID Sequence and Base ID"
on page 57 for more information.
4. Replace the front bezel.

Checking Back Panel LEDs

FIGURE 5-4

System Power and System Summary Fault LEDs

The System Power and System Summary Fault LEDs give the same diagnostic
information as the System Power and System Summary Fault LEDs at the front of
the array. Refer to
88 Sun StorEdge S1 Array Installation and Maintenance Manual • April 2003
System Power LED
System Summary Fault LED
Back Panel LEDs
for more information.
TABLE 5-1
Autotermination
Indication LEDs
