- Page 1 User’s Manual SUN-OCC-576SMC English Outdoor Fiber Optic Cross-connect Cabinets All the trademarks mentioned in this manual are registered property of Sun Telecom. The right to interpret this manual is reserved by Sun Telecom.
- Page 2 NOTICE Trademarks All trademarks mentioned in this manual are registered property of our company. Explanation The content of this manual is subject to our explanation. www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
- Page 3 Safe and reliable fiber optic storage and protection Specification Parameters Specification Model SUN-OCC-SMC576 Max. No. of Cores Max. No. of Splitters Cabinet Material FC square, SC, DLC (SC type), (ST and FC Adapter Panel small D type can be customized)
- Page 4 Fiber Optic Solutions Provider The installation of the cabinet 2.1 The installation and debugging of the cement 2.1.1 Prefabricate the cement as picture 1 below. Sketch of the prefabricated cement Dimension of the cement(H*L*W): 810mm×680mm×400mm Leave a 550mm×450mm×400mm hole for the wire to entry in the foundation center.
- Page 5 Fiber Optic Solutions Provider Picture 2 3.2 Strip fiber cable 3.2.1 Strip the fiber cable from where is 2800mm away from the end to strip. 3.2.2 Cut crosswise the outer sheath before stripping with the special stripping knife and carve scratch on the steel strip (but not cut) and then gently bend it back and forth until it break.
- Page 6 Fiber Optic Solutions Provider Picture 3 3.2.7 Clean up the optical fiber loose tube, strength member and wrapping cord. Please wipe outwards from integrated aluminum sheath breaking point, opposite direction is prohibited, to avoid the loose tube breaking. It is forbidden to use gasoline and other flammable solvent scrubbing in case of a fire.
- Page 7 Fiber Optic Solutions Provider 3.3.3 Fix the armored fiber cable to the cable fixed board with hose clamp and fix the strength member to the grounding copper column. 3.3.4 Connect the ground wire is to the cable fixing plate, and then connect it with room ground.
- Page 8 Fiber Optic Solutions Provider 4.3 4.3 Keep the excess part of the fiber cable bending naturally and the bending radius should be 20 times bigger than the diameter of the fiber cable. The opening direction (left or right) of the cabinet is up to the user. As long as the positioning pin is removed, you can change the opening just by rotating the door 180 degree.
-
Page 9: Your Opinion
Fiber Optic Solutions Provider An important message from Sun Telecom We guarantee that any information you supply will remain confidential. By returning this card, you will automatically be notified about updates, modifications, and recalibration. Warranty Registration Card Serial Number: Model Number: Date of Purchase: Company Name: Company Address:... - Page 10 Fiber Optic Solutions Provider SHANGHAI SUN TELECOMMUNICATION CO., LTD. Building No.145, Lane 666 Xianing Road, Jinshan Industrial Park, Shanghai 201506 China Tel: +86 21 60138638 Fax: +86 21 60138635 - 401 E-mail: ics@suntelecom.cn http: //www.suntelecom.cn/ www.suntelecom.cn • +86-21-60138638 • ics@suntelecom.cn...
