Figure 5-8 Pushing The Tether To One Side Until It Head Emerges; Figure 5-9 Pushing The Tether In The Opposite Direction; Figure 5-10 Pulling The Head Of The Tether Out Of The Array - Sun Microsystems StorEdge S1 Array Installation And Maintenance Manual

3. Push the tether to one side so that its head comes partially out of the hole in the
chassis (
FIGURE 5-8
4. Push the same tether in the opposite direction (
FIGURE 5-9
5. Pull the head of the tether entirely out of the chassis (
FIGURE 5-10
92 Sun StorEdge S1 Array Installation and Maintenance Manual • April 2003
).
FIGURE 5-8FIGURE 5-8
Pushing the Tether to One Side Until it Head Emerges
Pushing the Tether in the Opposite Direction
Pulling the Head of the Tether out of the Array
).
FIGURE 5-9
).
FIGURE 5-10
