- Page 1 ™ Sun StorEdge S1 Array Just the Facts (SunWIN token# 314474)
- Page 2 Copyrights © 1999, 2000, 2001 Sun Microsystems, Inc. All Rights Reserved. Sun, Sun Microsystems, the Sun logo, Sun StorEdge, Solaris, Sun Cluster, Sun Enterprise, Sun Fire, SunSpectrum, SunSwift, and Netra are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.
-
Page 3: Table Of Contents
Clustering............................5 Carrier−Grade Features........................5 Form Factor............................5 Daisy Chaining...........................5 Data Storage Capabilities........................6 System Architecture..........................7 Overview............................7 Sun StorEdge S1 Array Features and Benefits...................7 System Architecture...........................9 Disk Tray Key Facts...........................9 Storage Subsytem Manager.......................9 Enclosure Service..........................10 Front Panel Indicators ........................10 Rear Panel Indicators and Switches....................11 Sun StorEdge S1 Array DC Version....................12... - Page 4 Software............................20 Other Late Breaking News.......................20 Internationalization...........................20 Ordering Information..........................21 Base Models............................21 Other Base Models..........................21 Options............................21 Upgrades.............................23 Upgrade Paths..........................23 Service and Support...........................24 Warranty............................24 Education............................24 Glossary..............................25 Materials Abstract..........................27 Internal Information..........................28 Competitive Information........................28 Sun StorEdge S1 Array Just the Facts 314474.int.sdw 9/27/01...
-
Page 5: Sun Storedge™ S1 Array Positioning
The Sun StorEdge™ S1 array is a rackable, thin storage product that is 1 rack unit (1 U) high, with multiple rackmounting options. The Sun StorEdge S1 array can house up to three 18 GB or three 36 GB SCSI disk drives. This product is designed to be an affordable, versatile, rackmountable, incremental storage solution for a wide variety of markets. -
Page 6: Key Messages
Key Messages The Sun StorEdge S1 array delivers a high−performance, versatile, scalable, rack−optimized, and cost− effective solution for customers seeking to complement their existing Sun servers with incremental storage. Hot−swappable, incremental storage for Netra and Sun Enterprise™ servers and cluster applications 1 rack unit high, 18−inch depth, rackmount−ready enclosure... -
Page 7: Target Users
Target Markets Below are the industries and key features to highlight that are appropriate for the Sun StorEdge S1 array. Industry/Customer Key Features to Highlight •... -
Page 8: Selling Highlights
Hot−swappable, redundant system disks for Netra and other Sun servers Ruggedized storage for service providers and telecom Mirroring— by using up to four Sun StorEdge S1 array units and mirroring software on the host, build redundant system and data disks with no single point of failure... -
Page 9: Enabling Technology
Enabling Technology Technology Overview The Sun StorEdge S1 array provides up to 109 GB of storage (436 GB when daisy chained) incrementally, allowing users to add the amount of storage needed when it is needed. The hot− swappable, high performance disk drives can be connected directly to the Ultra SCSI port standard on Sun servers or to Ultra3 SCSI, Ultra2 SCSI, or Ultra SCSI SE host adapters. -
Page 10: Data Storage Capabilities
Connect up to four enclosures per SCSI chain Two−position switch allows quick selection of SCSI IDs 2, 3, 4 or 10, 11, 12 Supports standard SCA hot−swappable disk drive with spud brackets Sun StorEdge S1 Array Just the Facts 9/27/01... -
Page 11: System Architecture
System Architecture Overview The Sun StorEdge S1 array is a rackable thin storage with a 1 U form factor. Its versatility, rack− optimized and carrier−grade features make it ideally suited for a wide range of customers, from the telecom and service provider markets to enterprise customers in the financials, education, manufacturing, and health care arenas. - Page 12 Enables customer to easily label • Helps reduce overall operating bezel and identify units and maintenance costs • • • Auto termination No termination plugs needed Helps reduce overall operating and maintenance costs Sun StorEdge S1 Array Just the Facts 9/27/01...
-
Page 13: System Architecture
Figure 2. Sun StorEdge S1 Array Enclosure Disk Tray Key Facts Each Sun StorEdge S1 array disk tray holds a maximum of three, low profile, 3.5−inch, hot−pluggable disk modules. All drives are mounted in a spud bracket for easy installation and removal from the tray. -
Page 14: Enclosure Service
Enclosure Service Enclosure services provide and/or accept configuration and maintenance information. Information about the Sun StorEdge S1 array is obtained through physical inspection of the unit or through software (downloadable from the Web; refer to http://webhome.ebay/networkstorage/products for details.) The following components generate or receive enclosure status or control information:... -
Page 15: Rear Panel Indicators And Switches
Rear Panel Indicators and Switches Figure 5. Rear View Figure 6. SCSI ID Switch Figure 7. Rear Panel LEDs Sun StorEdge S1 Array Just the Facts 9/27/01... -
Page 16: Sun Storedge S1 Array Dc Version
Sun StorEdge S1 Array DC Version Figure 8 shows the back of the DC version of the Sun StorEdge S1 array chassis. Note that there are two DC connectors. DC connectors are available as an X−option and come in sets of 10. Two connectors are typically needed per Sun StorEdge S1 array. -
Page 17: Reliability, Availability, And Serviceability (Ras)
Can be used for high availability mirroring applications Can be used for high availability clustering applications Serviceability Status LEDs in the front and back of the Sun StorEdge S1 array indicate power and enclosure operating status Front−accessible, hot−swappable disk drives... -
Page 18: Installation Data
Overcurrent protection devices must be provided as part of each equipment rack. Circuit breakers must be located between the DC power source and the Sun StorEdge S1 array enclosure. Two 10−amp, double−pole, fast trip, DC−rated circuit breakers must be used for each power supply. -
Page 19: Chassis Dimension And Weight
19.4 lbs 8.8 kg Shipping Weight (product and 20 lbs 9.5 kg packing) Environment The Sun StorEdge S1 array is designed to meet the following requirements: Environmental Specifications Climate Control Location Minimum to Maximum Range Temperature (dry bulb) Operating 5°C to 40°C (41°F to 104°F) Storage –25°C to 65°C (–13°F to 149°F) -
Page 20: Regulations
Regulations The Sun StorEdge S1 array meets or exceeds the following requirements: Safety UL 1950, CSA C22.2−No. 950, EN 60650 (73/23/EEC), IEC 950 Emissions CFR Title 47, FCC Part 15, EN 55022 (89/336/EEC) Immunity EMC Directive (89/336/EEC), EN50082−1 Telecom environment Telcordia: GR−63−CORE, NEBS GR−1089−CORE,... -
Page 21: Requirements And Configuration
Requirements and Configuration System Requirements The Sun StorEdge S1 array requires Netra t1/T1,Netra t 1120/1125, Netra t 1400/1405, Netra ct 400/800, Sun Enterprise 220R, 420R, 3500–6500, 10000, Sun Fire 280R, 15K, 3800−3600 servers, or other Sun servers with an on−board Ultra3 SCSI LVD, Ultra2 SCSI LVD, or Ultra SCSI SE interface and/or host adapter. -
Page 22: Sun Storedge S1 Array Basic Configuration
Daisy chain (four enclosure maximum) Sun Cluster 2.2, 3.0 Refer also to the Sun StorEdge S1 Array Installation and Maintenance Manual. This guide contains detailed information about correct SCSI cabling for the Sun StorEdge S1 array. Sun StorEdge S1 Array Basic Configuration Figure 10. -
Page 23: Licensing/Usage
(use 0.5 to daisy chain the second unit) Figure 11 illustrates four Sun StorEdge S1 array units daisy chained to an Ultra3 SCSI LVD host system. Figure 11. Ultra3 SCSI Host System Refer to the Sun StorEdge S1 Array Installation and Maintenance Manual for detailed information. -
Page 24: System Management
For other late breaking news for the Sun StorEdge S1 array, go to: http://www.sun.com/storage/workgroup/s1 Internationalization The Sun StorEdge S1 array documentation is available in English. Go to the following Web site to get internationalization documentation: http://www.sun.com/storage/workgroup/s1 Sun StorEdge S1 Array... -
Page 25: Ordering Information
Ordering Information Base Models The following are some sample base models for the Sun StorEdge S1 array: Order Number Title and Description NS−XDSKS1−236GAC Sun StorEdge S1 array, AC Rackable thin storage for telecoms and service providers with: • 19" rackmount ready, 1 U ¥ 17.6" ¥ 18.6"... - Page 26 4−meter Ultra SCSI−3/SCSI−3 cable X1132A 0.8−meter Ultra SCSI−3/VHDCI cable X3832A 2−meter Ultra SCSI−3/VHDCI cable X3830A 4−meter Ultra SCSI−3/VHDCI cable X3831A 10−meter Ultra SCSI−3/VHDCI cable X949A Wago DC connector set, contains 10 extra DC connectors Sun StorEdge S1 Array Just the Facts 9/27/01...
-
Page 27: Upgrades
Upgrades Upgrade Paths An upgrade path is available to upgrade from Sun StorEdge UniPack/MultiPack and Netra st D130 storage arrays deployed in rackmount situations to the Sun StorEdge S1 array. Sun StorEdge S1 Array Just the Facts 9/27/01... -
Page 28: Service And Support
Customers should check with their local Sun Enterprise Services representatives for program and feature availability in their areas. Warranty The warranty on the hardware is one year, 15−day factory return. Education Support Readiness Training Sun StorEdge S1 Array Just the Facts 9/27/01... -
Page 29: Glossary
LVD is less costly than differential because transceivers are built into the controller chips. LVD also requires less power. Sun does not support LVD in servers or host adapters. Sun StorEdge S1 array is compatible with third− party LVD host adapters, although Sun does not formally support it. - Page 30 Ultra SCSI single−ended. Ultra3 SCSI LVD A SCSI interface that transfers 160 Mbytes/sec for 16−bit versions. The maximum cable length is 39.4 feet (12 m). Backwards−compatible with Ultra SCSI single− ended and Ultra2 SCSI. Sun StorEdge S1 Array Just the Facts 9/27/01...
-
Page 31: Materials Abstract
Sun Introduction Sales Tool SunWin 313045 with pricing and Q&A Product Literature Sun StorEdge S1 2−page color Sales Tool Field distribution 313862 Array Datasheet datasheet External Web Sites http://www.sun.com/storage/workgroup/s1 http://webhome.ebay/networkstorage/products/s1 Internal Web Sites Sun StorEdge S1 Array Just the Facts 9/27/01... -
Page 32: Internal Information
Certification 47.2cm / 18.6" 38.1cm / 15" 43.9cm / 17.3" 76.2cm / 30" 58.4 cm / 23" Depth Price* $2,295 – $4965 $2,404 – $7,096 No data Starts at $4,029 No data Sun StorEdge S1 Array Just the Facts 9/27/01...
