TABLE A-6
Signal Name
+MSG
+SEL
+C/D
+REQ
+I/O
+DB(8)
+DB(9)
+DB(10)
+DB(11)
1 The conductor number refers to the conductor position when using flat-ribbon cable.
102 Sun StorEdge S1 Array Installation and Maintenance Manual • April 2003
LVD SCSI Port Pin Descriptions (Continued)
Connector Cable
Contact Conductor
1
Number Number
26 51
27 53
28 55
29 57
30 59
31 61
32 63
33 65
34 67
Cable Connector
Conductor Contact
Number Number
52 60
54 61
56 62
58 63
60 64
62 65
64 66
66 67
68 68
Signal Name
-MSG
-SEL
-C/D
-REQ
-I/O
-DB(8)
-DB(9)
-DB(10)
-DB(11)
