FIGURE 5-5
FIGURE 5-6
HIGH Autotermination LED is On and LOW is Off on the array, which indicates that
a narrow SCSI device follows the array in the daisy chain.
FIGURE 5-6
90
Sun StorEdge S1 Array Installation and Maintenance Manual • April 2003
Host system
Autotermination Indication LEDs in an UltraSCSI or Wide SCSI Daisy Chain
shows an array and a narrow SCSI device daisy-chained to a server. The
Host system
Sun StorEdge S1 array
Autotermination Indication LEDs in a Narrow SCSI Daisy Chain
No Autotermination
Indication LEDs lit
Both High and Low
Autotermination
Indication LEDs lit
High Autotermination
Indication LED lit
Narrow SCSI device
