To Mount the Array Into a Four-Post Rack or
M
Cabinet
Note – See "Optional Rackmounting Kit for Four-Post Racks" on page 5 for how to
order the adjustable mounting brackets needed for a four-post rack or cabinet and
for a list of components in the bracket's ship kit.
This procedure can be used to install the Sun StorEdge S1 array into any of the four-
post racks shown in
each type of rack or cabinet.
TABLE 3-1
Rack/Cabinet
Sun StorEdge 72-inch Expansion Cabinet
Sun Rack 900 Cabinet
Sun Fire Expansion Cabinet
Industry standard 19-inch wide telco rack or cabinet
1. Remove the parts from the accessory kit envelope.
2. Use a Phillips screwdriver to attach the side mount brackets to the left and right
sides of the array using the M4 x 8 flat head screws from the accessory kit.
As shown in the following figure, the open slot on one end of each bracket extends
past the back of the array.
. The table shows the number of arrays that fit into
TABLE 3-1
Number of Arrays Supported in Supported Racks and Cabinets
Number of Arrays Supported
22 with cables that ship with the cabinet. If you
order X option cables, part number X319YA, you
can increase the number up to 32.
38
8 in Sun Fire 3800 and 4800 expansion cabinet
7 in Sun Fire 6800 expansion cabinet
Varies
Chapter 3 Installing the Sun StorEdge S1 Array
37
