- Page 1 StorageTek TIMBERWOLF™ 9740 Tape Library Hardware Operator’s Guide 95693 Revision: P...
- Page 3 TimberWolf 9740 Tape Library Hardware Operator’s Guide...
- Page 4 Copyright 2006 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, Californie 95054, Etats-Unis. Tous droits réservés. Sun Microsystems, Inc. a les droits de propriété intellectuels relatants à la technologie qui est décrit dans ce document. En particulier, et sans la limitation, ces droits de propriété intellectuels peuvent inclure un ou plus des brevets américains énumérés à http:// www.sun.com/patents et un ou les brevets plus supplémentaires ou les applications de brevet en attente dans les Etats-Unis et dans les...
-
Page 5: Summary Of Changes
Changes as noted in this revision. Changes as noted in this revision. Changes as noted in this revision. Covers and Title Page: Replaced the information with Sun Microsystems, Inc. information. Summary: Removed the List of Pages. Preface: Replaced Additional Information verbiage with Sun boilerplate verbiage. - Page 6 Revision P 95693...
-
Page 7: Table Of Contents
Contents Summary of Changes ........... . iii Contents . -
Page 8: Contents
Contents Tape Drives and Cabinets ............2-2 Controller Transport Units . - Page 9 Controller Transport Units ............4-1 9490 .
-
Page 10: Figures
Figures Figure 1-1. External Components ............1-2 Figure 1-2. - Page 11 Tables Table 1-1. LSM Specifications ............1-6 Table 3-1.
- Page 12 Tables Revision P 95693...
-
Page 13: Preface
Preface This guide describes how to operate the TimberWolf 9740 Library Storage Module (LSM). Most of the information in this guide pertains to the hardware. Note: Refer to the appropriate publications for specific information about the controller transport units, tape drives, software commands, and console messages. -
Page 14: Alert Messages
■ Alert Messages Alert messages call your attention to information that is especially important or that has a unique relationship to the main text or graphic. Note: A note provides additional information that is of special interest. A note might point out exceptions to rules or procedures. -
Page 15: Additional Information
■ Additional Information Sun Microsystems, Inc. (Sun) offers several methods for you to obtain additional information. Sun’s External Web Site Sun’s external Web site provides marketing, product, event, corporate, and service information. The external Web site is accessible to anyone with a Web browser and an Internet connection. - Page 16 Revision P 95693...
-
Page 17: Notices
Notices Please read the following compliance and warning statements for this product. CAUTION: Potential equipment damage: Cables that connect peripherals must be shielded and grounded; refer to descriptions in the cable instruction manuals. Operation of this equipment with cables that are not shielded and not correctly grounded might result in interference to radio and TV reception. -
Page 18: Japanese Compliance Statement
■ Japanese Compliance Statement The following compliance statement in Japanese pertains to VCCI EMI regulations: English translation: This is a Class A product based on the Technical Requirement of the Voluntary Control Council for Interference by Information Technology (VCCI). In a domestic environment, this product may cause radio interference, in which case the user may be required to take corrective actions. -
Page 19: Internal Code License Statement
■ Internal Code License Statement The following is the Internal Code License Agreement from Sun StorageTek: PLEASE READ THIS NOTICE CAREFULLY BEFORE INSTALLING AND OPERATING THIS EQUIPMENT. THIS NOTICE IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR ENTITY), THE END USER, AND STORAGE TECHNOLOGY CORPORATION (“STORAGETEK”), THE MANUFACTURER OF THE EQUIPMENT. - Page 20 information is not otherwise readily available); or (iii) sublicense, assign, or lease the Internal Code or permit another person to use such Internal Code, or any copy of If you need a backup or archival copy of the Internal Code, StorageTek, or your authorized StorageTek distributor or reseller, will make one available to you, it being acknowledged and agreed that you have no right to make such a copy.
-
Page 21: 1: General Information
General Information This chapter describes the library storage module (LSM) for an automated cartridge system (ACS). An ACS is a removable media, robotic system that mounts cartridges into storage cells, tape drives, cartridge access port (CAP), or cartridge exchange mechanism (CEM). Figure 1-1 on page 1-2 components for the LSM. -
Page 22: Robot
Library Storage Module Components Figure 1-1. External Components (C62619) DOOR LATCHES EXPANSION DOOR POWER SWITCH LOCATION Robot Figure 1-2 on page 1-3 moves cartridges between storage cells, CTUs, tape drives, CAP, or CEM. The robot consists of the Z column assembly, hand, and camera assembly. The Z column assembly contains a Z column, theta motor, and Z carriage. -
Page 23: Figure 1-2. Robot Components
Figure 1-2. Robot Components (C62012) CAMERA HAND STORAGE CELLS Z CARRIAGE The camera assembly on the hand reads the cartridge volume serial numbers (VOLSERs) during audits, but is not used to locate cartridges during robotic moves. An audit occurs when: •... -
Page 24: Cartridge Access Port
Library Storage Module Components Cartridge Access Port The cartridge access port (CAP) is a storage area where you add cartridges to or remove cartridges from an LSM. The CAP is located on the right front door. LSMs are shipped with the type of CAP that allows you to place 14 cartridges, one at a time, into the cells, or with a CAP that allows you to place a preloaded 10-cartridge magazine into the CAP. -
Page 25: Cartridge Drives And Cabinets
■ Cartridge Drives and Cabinets The cartridge drive attaches to the rear of the LSM and contains: • Two or four 9490 (TimberLine) CTUs • One to four SD-3 (RedWood) CTUs The 9741 or 9741E drive cabinets attach to the rear of the LSM and contains: •... -
Page 26: Lsm Specifications
LSM Specifications ■ LSM Specifications Table 1-1 lists the LSM specifications: Table 1-1. LSM Specifications Description Power cable Input voltage range Nominal voltage Power configuration Power consumption Maximum heat output Temperature Operating Storage Shipping Relative Humidity Operating Storage Shipping Wet Bulb Maximum Operating Storage Shipping... -
Page 27: 2: Controls And Indicators
Controls and Indicators This chapter shows and describes the power switch and operator panel for the LSM. It also describes how to set the SCSI address as well as the maximum usage count of the cleaning cartridges. Refer to the controller transport unit or tape drive operator guides for information about operating those units. -
Page 28: Tape Drives And Cabinets
Power Switch Tape Drives and Cabinets Drives that are housed in the standard and expanded (9741 and 9741E) Drive Cabinet each have their own power supply that attaches to a power strip at the base of the cabinet. To power down drives in the 9741/9741E Drive Cabinet the circuit breaker that provides power to the drives must be switched off. -
Page 29: Operator Panel
■ Operator Panel The operator panel is mounted to the right front door of the LSM. The panel contains function keys (also referred to as softkeys) and indicators, plus a two- line display. The operator panel displays LSM status, configuration, test sequences, and error information. -
Page 30: Figure 2-3. Operator Panel Function Keys, Indicators, And Displays
Setting the SCSI Address Figure 2-3. Operator Panel Function Keys, Indicators, and Displays (C62014) (OPERATOR PANEL DISPLAY) RESET Initiates the download from the diskette. The IPL sequence consists of PROM tests, boot tests, and machine initialization. RESET DESIGNED FOR CSE USE ONLY! NOT an operator activity. Initiates a dump. -
Page 31: Figure 2-4. Symbol Definitions For Menu Block Diagram
Figure 2-4. Symbol Definitions for Menu Block Diagram (C62015) Symbol Definitions for Menu Block Diagrams = display screen with actual display screen text from a top level menu Press Execute to = display screen with actual display screen text Enter 9740 = display screen and type of information screen is displaying Test Screens EXECUTE... -
Page 32: Figure 2-5. Setting The Scsi Address
Setting the SCSI Address Figure 2-5. Setting the SCSI Address (C62016) PRESSED Test Screens Download BT0.X Execute BT0.X Next Sequence of Tests Begin EXECUTE PRESSED MENU PRESSED EXECUTE MENU PRESSED PRESSED Press Execute to Enter 0 as ID EXECUTE MENU PRESSED PRESSED Press Execute to... -
Page 33: 3: Operating The Lsm
Operating the LSM This chapter contains the procedures for: • Powering-on or IPLing the LSM • Powering-off the LSM • Operating in automated mode • Operating in manual mode When the machine is controlled by the host, refer to your software publications and enter the command from the operator console to do the desired activity. -
Page 34: Operating The Lsm In Automated Mode
Operating the LSM in Automated Mode ■ Operating the LSM in Automated Mode When the LSM is online and operating in automated mode, it performs many tasks that you would otherwise perform manually. However, to keep the LSM operating efficiently while the robot is mounting and dismounting cartridges, you may need to do the following: •... -
Page 35: Figure 3-1. Loading A Cartridge Into The Cartridge Access Port
4. Close the CAP. The lock automatically engages. Notes: • The host software determines what happens when you enter a cartridge upside down or with an unreadable label. Under normal conditions, the camera on the hand audits the CAP and recognizes that a cartridge is present, but the hand does not move it. -
Page 36: Ejecting Cartridges Through The Cap
Operating the LSM in Automated Mode Ejecting Cartridges through the CAP Refer to your specific software publications for instructions about having the robot insert the desired cartridges into the CAP. To eject cartridges through the CAP: 1. Enter the VOLSERs of the cartridges you want ejected at the operator console. -
Page 37: Cleaning Drives In The Lsm
■ Cleaning Drives in the LSM Drive cleaning can be initiated either by the operator or by the backup application. The following information describes the functions the operator needs to perform to clean the drives. Operator-initiated cleaning is handled in one of two ways: •... -
Page 38: Setting The Cleaning Cartridge Usage Count
Cleaning Drives in the LSM Setting the Cleaning Cartridge Usage Count You can use the operator panel to set the maximum number of times a cartridge can be used to make sure that it is effective. Remember that each drive’s cartridge has a maximum number of cleans, and must be replaced when it expires. -
Page 39: Replacing Cleaning Cartridges
Replacing Cleaning Cartridges When an LSM operating in an SCSI control path environment is in AUTO CLEAN mode, the only method to use to replace an expired cleaning cartridge is by selecting the Change Cln Cart instructions. Notes: • Do not load cleaning cartridges through the door of the LSM because the cleaning usage will not increment. -
Page 40: Serial Interface
Cleaning Drives in the LSM Serial Interface If your control path is serial, these items are true: • You do not have the option of using the AUTO CLEAN function from the operator panel. • All drive cleaning is managed by and controlled through the host. The manner which ACSLS (Automated Cartridge System Library Software) handles automatic cleaning operations is defined in the ACSLS 5.3x System Administrator’s Guide, PN 34767. -
Page 41: Replacing Expired Cleaning Cartridges
To unlock the CAP: 1. Press EXECUTE a. The operator panel displays ONLINE CAP UNLK PENDING. b. The hand unlocks the CAP. c. The operator panel displays ONLINE CAP UNLOCKED. 2. Open the CAP to gain access to the cells. 3. -
Page 42: Operating In Manual Mode
Operating in Manual Mode ■ Operating in Manual Mode When an LSM is offline, you might be: • Opening the LSM front doors • Moving the robot • Locating a cartridge in the storage cells • Mounting and dismounting a cartridge •... -
Page 43: Figure 3-3. Opening Front Doors
Figure 3-3. Opening Front Doors (C62021) LATCH BOTTOM LATCH LSM with Standard Door 95693 Operating in Manual Mode LSM with Expansion Door LATCH LATCH (REF) DETAIL A Revision P C62021 3-11... -
Page 44: Moving The Robot
Operating in Manual Mode Moving the Robot After opening the LSM doors, you might need to move the robot to make it easier to access the stored cartridges or the drives. Read and observe the following caution before attempting to move any portion of the robot. -
Page 45: Rotating The Z Column
Rotating the Z Column CAUTION: Potential equipment damage: The Z column does not rotate a full 360 degrees. If you meet resistance when rotating it, do not force it. Rotate the Z column in the opposite direction. If you need to rotate the Z column, grasp it and carefully rotate it, as shown in If the Z column meets resistance and stops before the desired position is reached, it has contacted a stopping mechanism. -
Page 46: Locating A Cartridge In The Storage Cells
Operating in Manual Mode Locating a Cartridge in the Storage Cells Figure 3-6 through the cartridge storage cells in a typical LSM configuration. Note: There is a decal at the top of each column that also provides location information. Figure 3-6. Locating Cartridges–Top View (C62024) COLUMN 0 COLUMN 0 3-14... - Page 47 PANEL 3 PANEL 0 (EXPANSION) COLUMN COLUMN COLUMN COLUMN COLUMN COLUMN CUSTOMER CARTRIDGE CAPACITY CHART CTUs BASE EXPANSION TOTAL PANEL 1 COLUMN COLUMN COLUMN CTU 0 CTU 1 CTU 2 CTU 3 COLUMN COLUMN COLUMN T = ARRAY TARGET PANEL 2 COLUMN COLUMN COLUMN...
- Page 48 PANEL 3 PANEL 0 (EXPANSION) COLUMN COLUMN COLUMN COLUMN COLUMN COLUMN CUSTOMER CARTRIDGE CAPACITY CHART DRIVES BASE EXPANSION TOTAL PANEL 1 COLUMN COLUMN COLUMN DRIVE 9 DRIVE 8 DRIVE 7 DRIVE 6 DRIVE 5 DRIVE 4 DRIVE 3 DRIVE 2 DRIVE 1 DRIVE 0 COLUMN...
- Page 49 PANEL 3 PANEL 0 (EXPANSION) COLUMN COLUMN COLUMN COLUMN COLUMN COLUMN CUSTOMER CARTRIDGE CAPACITY CHART EXPANSION TOTAL DRIVES BASE 4 or 10 10 or 14 PANEL 1 COLUMN COLUMN COLUMN DRIVE PLENUM (4 OR 10-DRIVE CONFIGURATION) COLUMN COLUMN COLUMN NOT A STORAGE CELL T = ARRAY TARGET CLEANING CARTRIDGE CELL DIAGNOSTIC CARTRIDGE CELL...
-
Page 50: Figure 3-10. Diagnostic And Cleaning Cartridge Cell Locations
Operating in Manual Mode Figure 3-10. Diagnostic and Cleaning Cartridge Cell Locations (C62733) ROW 22 Do Not Use ROW 23 ROW 25 ROW 27 (Drop off Cell) Figure 3-10 shows the cell locations of cartridges stored in the playground. These cells are used to store diagnostic and cleaning cartridges, and to provide an empty/dropoff cell for the robot if the LSM loses power while a cartridge is in the hand. -
Page 51: Mounting And Dismounting Cartridge Tapes
Table 3-1. Playground Cartridge Locations Drive Combinations 9490 SD-3 9490 SD-3 T9840 T9940 T9840 T9940 T9840 T9940 Note: No more than two drive types can be mixed in the 9741/9741E Drive Cabinet. Mounting and Dismounting Cartridge Tapes When you are operating in manual mode, you may need to mount and dismount cartridge tapes from different types of CTUs and tape drives. -
Page 52: Mounting A Cartridge Into A 9490 Or Sd-3 Ctu
Operating in Manual Mode Mounting a Cartridge into a 9490 or SD-3 CTU “Controller Transport Units” on page 4-1 WARNING: Personal injury: To avoid injury to your hand, keep your fingers out of the transport; the elevator lowers automatically when a cartridge is inserted. -
Page 53: Mounting A Cartridge Into A Dlt Drive
Mounting a Cartridge into a DLT Drive Figure 3-11 procedures: Figure 3-11. DLT Handle and Hub Positions CARTRIDGE HOOK (UP) HANDLE VIEW A HANDLE DOWN POSITION 95693 “Digital Linear Tape Drives” on page 4-4 DRIVE CARTRIDGE (UP) HOOK (DOWN) HANDLE OPERATE HANDLE INDICATOR... -
Page 54: Figure 3-12. Mounting A Dlt Cartridge
Operating in Manual Mode CAUTION: Potential equipment damage: Before mounting a cartridge into the drive, make sure that power is on, and that the Operate Handle indicator is on. Use the drive shuttle to operate, not the drive handle. A safety mechanism protects the drive if you try to operate it in an incorrect state. -
Page 55: Dismounting A Cartridge From A Dlt Drive
4. Insert the cartridge into the shuttle and push the cartridge into the back of the drive until it is firmly seated. 5. Push the shuttle completely back, pause for about two seconds, then release the shuttle. CAUTION: If the cartridge has been ejected from the drive, you must remove it from the shuttle before you can reload it into the drive. -
Page 56: Mounting A Cartridge Into A T9840 Drive
Operating in Manual Mode Mounting a Cartridge into a T9840 Drive Important: T9840A/B and T9840C VolSafe cartridges are not interchangeable. T9840C tape drives can read the 20-GB VolSafe tape cartridges used in T9840A and T9840B drives, but cannot write to them. The 40-GB VolSafe tape cartridges used in T9840C drives cause a load error when mounted in a T9840A or T9840B drive. -
Page 57: Dismounting A Cartridge From A T9840 Drive
Figure 3-13. Mounting a Cartridge into a T9840 Drive (E62446) 9840 CARTRIDGE Dismounting a Cartridge from a T9840 Drive To unload the cartridge from a T9840 drive: 1. Ensure that the drive is not selected. CAUTION: Loss of data: Pressing the Unload switch during a write operation causes the drive to try to write the remaining data before the tape unloads. -
Page 58: Mounting A Cartridge Into A T9940 Drive
Operating in Manual Mode Mounting a Cartridge into a T9940 Drive “T9840 and T9940 Tape Drives” on page 4-5 To load the cartridge in a T9940 drive: 1. Follow the steps in 2. Insert the cartridge into the drive as shown in 3. -
Page 59: Removing A Cartridge From The Hand
Figure 3-14. Mounting a Cartridge into a T9940 Drive (C62732) T9940 CARTRIDGE Removing a Cartridge from the Hand If the LSM goes offline because of a power failure, a cartridge might be left in the hand. If you need the cartridge to complete a job request, you can manually remove it from the hand and mount it into a drive for a read/write operation. -
Page 60: Expansion Door Procedure
Operating in Manual Mode 5. Turn the reach mechanism drive belt until the gripper is fully retracted. 6. If a cartridge was in the top cell, re-insert it properly into the cell. Expansion Door Procedure To remove a cartridge from the hand when your LSM has an expansion door: 1. -
Page 61: Returning The Lsm Online
Figure 3-16. Removing a Cartridge from the Hand (C62027) GRIPPER MECHANISM Returning the LSM Online To place the LSM online for automated operations: 1. Refer to your specific drive publications for instructions about making the drives ready. For DLT, make sure that the Operate Handle light is on and the handle is up. 2. - Page 62 Operating in Manual Mode 3-30 Revision P 95693...
-
Page 63: Controller Transport Units
Drives This chapter contains an overview about the controller transport units (CTUs) and tape drives for the 9740 Library Storage Module (LSM). Note: See Appendix A CTUs mount in cartridge drives that attach to the rear of the LSM. Each cartridge drive can contain: •... -
Page 64: Power Switch
Controller Transport Units 9490 The 9490, also known as TimberLine, is a high-performance information storage and retrieval system that uses Extended Enhanced tape (called EETape), Enhanced Capacity cartridge tape (called E-Cart or E-Tape), and standard length cartridges as the storage medium. -
Page 65: Figure 4-1. Power Control Panel
Controller Transport Units Figure 4-1. Power Control Panel C42052 Figure 4-2. Library Operator Panel OPERATOR OFFLINE CLEAN CRTG LOADED REWIND UNLOAD READY SELECT C42431 95693 Revision P... -
Page 66: 9741/9741E Drive Cabinet
9741/9741E Drive Cabinet ■ 9741/9741E Drive Cabinet The drive cabinet houses from 1 to 10 DLT, 9840, T9840, or T9940 tape drives or a combination of these tape drives. Digital Linear Tape Drives Digital Linear Tape (DLT) drives mount inside a 9741/9741E Drive Cabinet. These drives are high-performance, large-capacity, streaming cartridge tape products. -
Page 67: T9840 And T9940 Tape Drives
T9840 and T9940 Tape Drives The T9840 Tape Drives are small, modular, high-performance tape drives. These drives are designed for fast-access tape storage of data. Three models are currently available, T9840A and T9840B, which are 20-GB drives and T9840C, which is a 40-GB drive. The T9840 Tape Drives use cartridge tapes that have the same physical size as 3490 or T9940 cartridge tapes;... -
Page 68: Operator Panel
9741/9741E Drive Cabinet Operator Panel Figure 4-4 is an example of the operator panel: Figure 4-4. T9840/T9940 Operator Panel A C T IV IT Y IN D IC A T O R P O W E R IN D IC A T O R L O A D IN G U N L O A D S L O T... -
Page 69: 5: Service
Microsystems StorageTek Support. You receive immediate attention from qualified Sun personnel, who record problem information and respond with the appropriate level of support. To contact Sun Microsystems StorageTek Support about a problem: 1. Use a telephone to call the StorageTek Customer Services Support Center at: ☎... -
Page 70: Sun's Worldwide Offices
Sun’s Worldwide Offices 2. Describe the problem to the call taker. The call taker will ask several questions and will either route your call to a trained support technician or dispatch a service representative. If you have the following information when placing a service call, the process will be much easier: Account name Site location number... -
Page 71: A: Cartridge Tape Information
Cartridge Tape Information This appendix contains information about the cartridge tapes used in the controller transport units (CTUs) and tape drives for the LSM. ■ Cartridge Requirements Cartridges must meet specifications defined in American National Standard Magnetic Tape and Cartridge for Information Interchange, ACS X3B5. Refer to your drive vendor’s publication and Web site for specific cartridge requirements and specifications. -
Page 72: Inspecting A Cartridge
Inspecting a Cartridge ■ Inspecting a Cartridge A defective or dirty cartridge can damage a drive. Always inspect a cartridge before inserting it into a drive or a library. Look for: • Cracked or broken cartridge • Broken leader block •... -
Page 73: Figure A-2. Inspecting An Sd-3 Helical Scan Cartridge
Figure A-2. Inspecting an SD-3 Helical Scan Cartridge WRITE- PROTECT SWITCH Figure A-3. Inspecting a DLT Cartridge TAPE LEADER 95693 LABELS DETENT SPRINGS LEADER BLOCK C62030 WRITE- PROTECT C62380 SWITCH Revision P Inspecting a Cartridge... - Page 74 Inspecting a Cartridge Figure A-4. Inspecting a T9840 Cartridge (C62715) MANUFACTURER LABEL AREA MEDIA ID LABEL Figure A-5. Inspecting a T9940 Cartridge (C62727) TAPE LEADER BLOCK FRONT VIEW CUSTOMER LABEL AREA FINGER GRIPS VOLSER LABEL REAR VIEW MANUFACTURER LABEL AREA WRITE MEDIA PROTECT...
-
Page 75: Storing Cartridges
■ Storing Cartridges When storing a cartridge: • Do not take a cartridge out of its protective wrapping until you are ready to use it. Use the tear string, not a sharp instrument, to remove the wrapping. • Store cartridges in a clean environment that duplicates the conditions of the room in which they are used. -
Page 76: Repairing A Detached Leader Block
Repairing a Detached Leader Block When a cleaning cartridge is used the specified number of times, it is automatically placed into the CAP, and the operator panel displays “(3480, SD-3, DLT, T9840, or T9940) CLEANING CART USED UP.” See Cleaning Cartridges” in Chapter 3, “Operating the LSM,” ■... -
Page 77: Applying Labels
■ Applying Labels Cartridge labels reflect the cartridge media and usage. The types of cartridge labels you might need to apply are: • Customer • VOLSER • Cleaning • Diagnostic • Media labels Notes: • Make sure that the labels are not placed elsewhere on the cartridge surface. •... - Page 78 Applying Labels Figure A-6. 3480 Cartridge Label Locations (C62031) CUSTOMER LABEL VOLSER LABEL Figure A-7. ETape Cartridge Label Locations (C62528) CUSTOMER LABEL MEDIA LABEL VOLSER LABEL Revision P C62031 C62528 95693...
- Page 79 Figure A-8. EETape Cartridge Label Locations (C62526) CUSTOMER LABEL MEDIA LABEL “Z” VOLUME/ SERIAL NUMBER (VOLSER) LABEL Figure A-9. Helical Scan Cartridge Label Locations (C62032) CUSTOMER LABEL TAPE LENGTH VOLUME/ LABEL SERIAL NUMBER (VOLSER) LABEL 95693 WRITE- PROTECT SWITCH Revision P Applying Labels C62526 C62032...
- Page 80 Applying Labels Figure A-10. T9840 Cartridge Label Locations (C62444) MEDIA ID LABEL VOLSER LABEL Figure A-11. T9940 Cartridge Label Location (C62731) MANUFACTURER LABEL AREA MEDIA VOLSER LABEL AREA A-10 CUSTOMER LABEL CUSTOMER LABEL AREA C62731 Revision P WRITE- PROTECT C62444 95693...
-
Page 81: Dlt Cartridges
DLT Cartridges The DLTtape VOLSER letter located next to the last number in the VOLSER reflects the media. Cleaning cartridges have CLN in the VOLSER, diagnostic cartridges have DG in the VOLSER. Figure A-12 and insert the label into the recessed area on each cartridge: 1. -
Page 82: Setting The Write-Protect Switch
Setting the Write-Protect Switch ■ Setting the Write-Protect Switch Write-protect, also called file-protect, is a setting on cartridge tapes that prevents data form being written on the tape but reading data is still possible. Write-enable is a setting that allows data to be written on the tape. Notes: •... - Page 83 Figure A-14. Setting the ETape Write-Protect Selector (C62529) WRITE- PROTECTED POSITION UNPROTECTED POSITION Figure A-15. Setting the EETape Write-Protect Selector (C62523) LEADER BLOCK (TYPICAL) WRITE- PROTECTED POSITION (WRITE DISABLED) WRITE- PROTECTED POSITION (WRITE ENABLED) 95693 Setting the Write-Protect Switch Revision P C62529 LABEL LOCATIONS...
-
Page 84: Sd-3 Write-Protect Switch
Setting the Write-Protect Switch SD-3 Write-Protect Switch To write-enable an SD-3 cartridge: 1. Hold the cartridge with the write-protect switch towards you. 2. Locate the write-protect switch on the front of the cartridge. 3. Slide the write-protect switch to the right so that the pencil icon is joined. To write-protect this cartridge, slide the switch to the left so that the pencil icon is split. -
Page 85: Dlt Write-Protect Switch
DLT Write-Protect Switch To write-enable a DLT cartridge: 1. Hold the cartridge with the rear VOLSER label toward you. 2. Locate the write-protect switch on the front of the cartridge. 3. Slide the write-protect switch to the right so that the orange indicator is not visible. To write-protect this cartridge, slide the switch to the left so that the orange indicator is visible. -
Page 86: T9840 Write-Protect Switch
Setting the Write-Protect Switch T9840 Write-Protect Switch To write-enable a T9840 cartridge: 1. Hold the cartridge with the customer label side up and rear VOLSER label toward you. 2. Locate the write-protect switch on the right side of the cartridge. 3. -
Page 87: T9940 Write-Protect Switch
T9940 Write-Protect Switch 1. Hold the cartridge with write-protect switch towards you. 2. Locate the write-protect switch on the front of the cartridge. 3. Slide the write-protect switch to the left so the arrow points to the unlocked padlock icon. To write-protect this cartridge, slide the write-protect switch to the right so the arrow points to the locked padlock icon. -
Page 88: Environmental Specifications
Environmental Specifications ■ Environmental Specifications The following tables list the different cartridge environmental specifications: Table A-1. 9490 Cartridge Environmental Specifications Operating Environment Temperature Relative humidity Wet bulb temperature Cartridge Storage Environment Temperature Relative humidity Wet bulb temperature Table A-2. SD-3 Cartridge Environmental Specifications Operating Environment Temperature Relative humidity... -
Page 89: Table A-4. T9840 Cartridge Environmental Specifications
Table A-4. T9840 Cartridge Environmental Specifications Operating Environment Temperature Relative humidity Wet bulb temperature Cartridge Storage Environment Temperature Archive Non-archive Relative humidity Archive Non-archive Wet bulb temperature Table A-5. T9940 Cartridge Environmental Specifications Operating Environment Temperature Relative humidity Wet bulb temperature Cartridge Storage Environment Temperature Archive... - Page 90 Environmental Specifications A-20 Revision P 95693...
-
