Workstation 5 System Board Technical Descriptions

Workstation 5 System Board Block Diagram

Workstation 5 System Board Block Diagram
Figure 2-1 displays a block diagram of the Workstation 5 with the standard
resistive touchscreen. This configuration represents production units from
January 2008 to February 2009.
Figure 2-1: Workstation 5 Block Diagram /w Resistive Touchscreen
2-2 Workstation 5 Field Service Guide
