Introduction to the WS5 FRUs
Casework and Mag Card Reader
•
Door, /w Logo Insert, Workstation 5 - P/N 300323-105
Snap-in IO Door with removable MICROS logo insert.
•
Base, Workstation 5 - P/N 400408-005
The plastic base holds the chassis, system board, power supply and Mag
Card Reader assembly. Mounting hardware, Mag Card Reader assembly
and power button actuator not included.
•
Mag Card Reader Assembly, MCR /w Cable and Cover - P/N 700293-125
Fully assembled Magnetic Card Reader /w cable and plastic mounting
bracket.
•
Power Button Actuator, /w Light Pipe and Screw - P/N 300103-011
Power button actuator assembly includes light pipe and mounting screw.
Mounts to the base to activate the System Board power switch.
1-4 Workstation 5 Field Service Guide
