Workstation 5 Troubleshooting
WS5 Diagnostic
BIOS Version
This field displays the current BIOS Version. Again, the 'G' represents
'Greenbelt' the internal project name for the Workstation 5.
Other Platform Files and Folders
Several other platform related files are located on the \DOC partition
that do not appear on the System Information Screen. These files use
either a .DAT extension or no extension. By default, Windows hides
many file extensions including .DAT. To see all files, touch View -
Options and remove the three check boxes found in the 'Folder
Options' window.
\DOC\PoleConfig
The Workstation 4 LX and Workstation 5 share the ability to
auto-detect the type of customer display installed. Therefore the
PoleConfig file is no longer required.
\DOC\MSRConfig
This file is read by the API at start-up to determine if a carriage return
should be appended to Magtek Mode card data.
o
o
\DOC\FACRECOV.DAT
This file contains information about the Windows CE Factory Restore
feature. When the unit ships, this file contains a single line - the GR
Version of the Windows CE Factory Restore Files.
Each time the Windows CE Factory Restore feature is used, the time
and date are appended to this file. The contents of this file are displayed
by the WS5DiagUtility when you press the [Recovery Image Info]
button.
\DOC\HWInf\
This folder contains several INF files that determine the backlight
brightness ranges and settings. Each file is specific to a given brand and
model of LCD panel.
For example, the unit ships with a Sharp LG45 LCD Panel. A pair of
jumpers located on the Backlight Inverter Board are set to 'Sharp'. At
start-up, the WS5 API reads the jumpers and selects the appropriate
INF file, in this case the lxvideo_sharp.inf file.
3-40
If MSRConfig is not present or contains the statement
'Magtek_CR=0, a carriage return character is NOT appended to the
mag card data track.
If MSRConfig is present and contains the line 'Magtek_CR=1, a
carriage return is appended to the mag card data track.
