Dongle, Rj45-Db9, Idn Port To Rs232 2-Wire Serial; Serial Port Conversion Dongle, Com5 Rj45 To Db9 - Micros Systems Workstation 5 Service Manual

Dongle, RJ45-DB9, IDN Port to RS232 2-Wire Serial - P/N 300319-102
This cable brings out the RS232 conductors from the IDN port to a DB9
connector.
Figure 1-9: Converting the IDN Port to RS232 DB9
Serial Port Conversion Dongle, COM5, RJ45 to DB9 - P/N 300319-103
This cable converts the modular COM5 serial connector to a DB9 connector.
Figure 1-10: Converting the Modular COM5 Port to RS232 DB9
Workstation 5 Field Service Guide
Introduction to the WS5 FRUs
Cables
1-11
