Remove and Replace the Workstation 5 FRUs
The System Board
Approved DIMMs for the Workstation 5 System Board
Figure 4-24 lists the DDR DIMMs currently approved for use on the
Workstation 5 System Board..
Size
256MB
512MB
1GB
Figure 4-24: Workstation 5 System Board Approved DIMMs
Figure 4-25 displays current DDR 333 DIMM configurations for the Windows
CE and WEPOS operating systems using MICROS approved devices.
CN12
256MB
512MB
1GB
a. MICROS recemmneds that you do not install more than 512MB in
a WS5 running Windows Embedded CE 6.0.
4-22
MICROS P/N
700502-175 Wintec WD1UN256X808-333B-PH
WD1UN256X808-333B-PJ-M01
Unigen UG732D6688KV-DHFMSS
700502-173 Wintec WD1UN512X808-333B-QC
WD1UN512X816-333B-PJ-M01
700502-174 Wintec WD1UN01GX816-333C-QC
CN13 Total
-- 256MB
-- 512MB
--
Figure 4-25: DIMM Configuration Table
Description
Operating System
Windows Embedded
CE 6.0
WEPOS
1GB WEPOS
Workstation 5 Field Service Guide
