Appendix B

Connector and Cable Diagrams

On the pages that follow, you will find diagrams of the Workstation 5
I/O Panel connectors, system board connectors, and commonly used
hook-up cables. A description of how each cable or connector is used is
provided.
In this appendix
IO Panel Connectors .................................................................................... B-2
System Board Connectors............................................................................B-6
Hook-up Cables ...........................................................................................B-7
