■ Error code 10
(Non Touch panel model)
Registration
Registration failed. Press Start, and try again.
(Touch panel model)
Registration failed
Press Start, and try again.
Inter-color position alignment adjustment failure. (Error, which cannot be recorded, occurs.)
Step
1 Main PCB failure
■ Error code 11
(Non Touch panel model)
Registration
Registration failed. Press Start, and try again.
(Touch panel model)
Registration failed
Registration failed. Press Start, and try again.
Inter-color position alignment adjustment failure.
(Toner of the color which is being used reached the end of life.)
<User Check>
- Replace the toner cartridge of the color displayed on the LCD.
Step
1 Main PCB failure
Cause
Cause
2-33
Remedy
Replace the main PCB ASSY.
Remedy
Replace the main PCB ASSY.
