(20) Remove the Second side scanning CIS flat cable from the Main body.
Main body
Assembling Note:
When attaching the Second side scanning CIS flat cable, be sure to attach the Film as
shown in the figure below.
Main body
Fig. 7-64
Film
Flat core
Flat core
Fig. 7-65
7-36
Second side scanning
CIS flat cable
Flat core
<Left side>
Film
Second side scanning
CIS flat cable
Second side scanning
CIS flat cable
Film
Main body
