(34) Remove the Main insulation sheet from the Top drive ASSY.
Top drive ASSY
Main insulation sheet
(35) Remove the seven Taptite cup S M3x8 screws and Taptite cup S M3x6 SR screw from the
Joint cover base ASSY.
Taptite cup S M3x8
Main body
<Left side>
Fig. 7-78
Taptite cup S M3x8
Fig. 7-79
7-43
Joint cover base ASSY
Taptite cup S M3x6 SR
Taptite cup S
M3x8
<Front>
