(5) Remove the Shoulder screw from the PF ASSY.
(6) Remove the two Taptite bind B M4x12 screws, then shift the PF ASSY to the right, and
remove it from the Base frame unit.
Base frame unit
Shoulder screw
PF ASSY
Taptite bind B M4x12
Fig. 3-304
Harness routing: Refer to
"
PF ASSY"
3-201
