HP Integrity rx6600 User's & Service Manual page 105

b. Insert the processor tool into the hole that runs down the side of the heatsink.
c. Rotate the processor tool counterclockwise 180 degrees.
CAUTION
d. Refasten the processor install tool to the tool holder on the processor board.
Step 9. Remove the dual-core processor from the processor slot.
a. Carefully grasp the sheet metal that encases the processor.
b. Pull the processor straight up and out of the chassis.
Step 10. Protect the processor from damage.
a. Install the protective pin cover on the processor connectors to shield the connector pins.
b. Place the dual-core processor in an antistatic container.
Chapter 4
The zero insertion force (ZIF) socket for the processor is locked and unlocked by
half of a full turn of the processor install tool. The counterclockwise 180 degree
rotation (half turn) unlocks the socket. A clockwise 180 degree rotation locks the
socket. Attempting to turn the locking mechanism more than 180 degrees can
severely damage the socket.
Removal and Replacement
Removing and Replacing a Dual-Core Processor
105
