Access Control - TP-Link Archer C7 AC1750 User Manual

2. Click "Access Control → Schedule" on the left to enter the Schedule Settings page. Click
Add New... button to create a new schedule with Schedule Description is Schedule_1, Day is
Sat and Time is all day-24 hours.
3. Click "Parental Control" menu on the left to go back to the Add or Modify Parental Control
Entry page:
1) Click Add New... button.
2) Enter 00-11-22-33-44-AA in the MAC Address of Child PC field.
3) Enter "Allow Google" in the Website Description field.
4) Enter "www.google.com" in the Allowed Domain Name field.
5) Select "Schedule_1" you create just now from the Effective Time drop-down list.
6) In Status field, select Enable.
4. Click Save to complete the settings.
Then you will go back to the Parental Control Settings page and see the following list, as
shown in Figure 4-72.

4.15 Access Control

Figure 4-73 Access Control
There are four submenus under the Access Control menu as shown in Figure 4-73: Rule, Host,
Target and Schedule. Click any of them, and you will be able to configure the corresponding
function.
Archer C7 AC1750 Wireless Dual Band Gigabit Router
Figure 4-72 Parental Control Settings
- 81 -
