Schedule - TP-Link Archer C7 AC1750 User Manual

For example: If you desire to restrict the internet activities of host with MAC address
00-11-22-33-44-AA in the LAN to access
settings below:
1. Click Add New... button in Figure 4-83 to enter the Add or Modify an Access Target Entry
page.
2. In Mode field, select Domain Name from the drop-down list.
3. In Target Description field, create a unique description for the target (e.g. Target_1).
4. In Domain Name field, enter www.google.com.
5. Click Save to complete the settings.
Then you will go back to the Target Settings page and see the following list.
4.15.4

Schedule

Choose menu "Access Control → Schedule", and then you can view and set a Schedule list in
the next screen as shown in Figure 4-86. The Schedule list is necessary for the Access Control
Rule.
Schedule Description - Here displays the description of the schedule and this description is

unique.
Day - Here displays the day(s) in a week.

Time - Here displays the time period in a day.

Modify - Here you can edit or delete an existing schedule.

To add a new schedule, follow the steps below:
1. Click Add New... button shown in Figure 4-86 and the next screen will pop-up as shown in
Figure 4-87.
2. In Schedule Description field, create a unique description for the schedule (e.g.
Schedule_1).
Archer C7 AC1750 Wireless Dual Band Gigabit Router
www.google.com
Figure 4-86 Schedule Settings
- 91 -
only, you should first follow the
