5.3.14 Visual Automation

The Visual Automation allows you to change the current state of the electronic device by
simply clicking on its image, e.g. turning the light ON. This feature is only available when the
Visual Automation is set ahead by the Administrator. For details, see 6.1.4 Visual Automation.
To access this feature, click the I/O Control button (No. 8, Figure 5-5) and select Visual
Automation.
To change the style of the set areas, click the green I/O button on the top left corner. You
will have these options:
Show All: Displays all set areas.
Rec Float: Embosses all set areas.
Set Color: Changes the frame color of all set areas

5.3.15 Network Status

To view the network status, in the left menu, click Network and select Status.
90
Figure 5-16
Figure 5-17
