5.3.13 I/O Control

The I/O Control window provides real-time graphic displays of camera and I/O status, and
alarm events. Additionally, you can force output to be triggered.
To display the I/O control window, click the I/O Control button (No. 8, Figure 5-5).
The Alarm List is displayed in three levels. The first level indicates date, the second
indicates time, and the third indicates alarm ID. Clicking the Reset button will clear the
list.
To trigger an output device, highlight an output and then click the Output button.
Remote Viewing Using a Web Browser
5
Figure 5-15
89
