5.3.2 The Control Panel of the Live View Window

To open the control panel of the Live View window, click the arrow button on top of the window.
You can access the following functions by using the right and left arrow buttons on the control
panel.
[Information] Displays the version of the GV-Compact DVR V2, local time of the local
computer, host time of the GV-Compact DVR V2, and the number of users logging in to the
GV-Compact DVR V2.
[Video] Displays the current video codec, resolution and data rate.
[Audio] Displays the audio data rates when the microphone and speaker devices are
enabled.
[I/O Control] Provides a real-time graphic display of the input and output status. You can
force the output to be triggered by double-clicking its icon.
[Alarm Notify] Displays the captured images by sensor triggers and/or motion detection. For
this function to work, you must configure the Alarm Notify settings first. See 5.3.6 Alarm
Notification.
[Camera Adjustment] Allows you to adjust the image quality.
[GPS] For details see 8.3 GPS Tracking.
[Download] Allows you to install the programs from the hard drive.
Remote Viewing Using a Web Browser
5
Click the arrow button to display the control
panel.
Figure 5-6
Click the right and
left arrow buttons to
change the page of
the control panel.
