[Name]
Rename the camera. To display the camera name on the image, see 5.3.9 Camera Name
Display.
[Video Signal Type]
Auto detect signal type on booting: Automatically detects the type of video input is
NTSC or PAL.
There are 4 options for selecting image resolutions.
NTSC
704 x 480
704 x 480 De-interlaced (Default)
352 x 240
352 x 240 3GPP v7
There are several frame rates available.
Frame Rate
2, 3, 5, 7.5, 10, 15, 30 (Default)
NTSC
PAL 2.5, 5, 8, 12.5, 25 (Default)
[Bandwidth Management]
When using MPEG-4 or H.264, it is possible to control the bitrate, which in turn allows the
amount of bandwidth usage to be controlled.
VBR (Variable Bitrate): The quality of the video stream is kept as constant as possible at the cost
of a varying bitrate. The bandwidth is much more efficiently used than a comparable CBR. Set the
image quality to one of the 5 standards: Poor, Fair, Good, Great and Excellent.
CBR (Constant Bitrate): CBR is used to achieve a specific bitrate by varying the quality of the stream. T
bitrates available for selection depend on the image resolution.
[GOP Structure and Length]
Set the maximum number of frames between every key frame. The limit is 1 key frame for
every 120 frames.
94
PAL
704 x 576
704 x 576 De-interlaced (Default)
352 x 288
352 x 288 3GPP v7
