3.2 Connecting Anti-Vibration Model

It is easy to connect the Anti-Vibration model to a vehicle. Using the supplied Cigarette
Lighter Power Adaptor, connect one end to the DC power input on the GV-Compact DVR V2
and the other end to a car's cigarette lighter socket. The car battery will supply power to the
unit.
You can also use the supplied Camera Power Cable to power on your cameras through the
vehicle power supply. For details on connecting the Camera Power Cable to the I/O terminal
block on the unit, see 12.3 Camera Power Supply.
Note:
1. Standard and Anti-Vibration models have different internal designs. It is forbidden to
connect Standard model to the vehicle power supply.
2. The Camera Power Cable can also be applied on the standard model.
3. Before you power on the unit, ensure to lock the HDD drive bay. Or the HDD Power LED
will not turn on when you power on the unit.
4. If any video is lost after startup, the buzzer will start beeping. To stop beeping, press any
button on the Remote Control.
5. When you want to remove the hard disk from the unit, please press the Storage Removal
button on the unit for five seconds to stop recording first.
16
Figure 3-2
