Rtsp / 3Gpp - GeoVision GV-Compact DVR V2 User Manual

6.3.9 RTSP / 3GPP

The RTSP / 3GPP Server enables video and audio streaming to your 3G-enabled mobile
phone. For details on the RTSP command, see RTSP Protocol Support in Appendix E. For
details on video streaming to the 3G-enabled mobile phone, see Chapter 9 Mobile Phone
Surveillance.
Figure 6-25
Activate Link: Enable the RTSP / 3GPP service.
RTSP/TCP Port: Keep the default value 8554, or modify it if necessary.
RTP/UDP Port: Keep the default range from 17300 to 17319, or modify it if necessary.
The number of ports for use is limited to 20.
Max Connection: Set the maximum number of connections to the GV-Compact DVR V2.
The maximum value is 20.
Enable Audio: Enable audio streaming.
124
