4.4 Monitoring Settings

You can start recording manually, by schedule or by input trigger.
MONITORING MODE:
Select MANUAL to manually start recording or I/O monitoring. If you choose this
option, configure the following item CHANNEL (CH 1 – CH 4) or INPUT.
Select SCHEDULE to start recording and I/O monitoring by the schedule you set up.
To configure recording schedule, see 4.5 Recording Schedule.
CHANNEL (CH 1 - CH 4): Available only in MANUAL monitoring mode. Select the desired
channel, and set its recording mode to motion detection or round-the-clock. You can also
select to turn off the channel.
INPUT: Available only in MANUAL monitoring mode. Select ON to start I/O monitoring
manually. When the input is triggered, its associated cameras and outputs will also be
enabled for recording and alerting. For input settings, see 4.2.1 Digital Input Settings.
START MONITORING BY: Start monitoring with a triggered input. When the assigned
input is triggered, the system will response based on your settings in either MANUAL or
SCHEDULE monitoring mode.
STOP MONITORING BY: Stop monitoring with a triggered input. When the assigned input
is triggered, the system will stop monitoring.
To start monitoring or recording:
•
Select START. The unit will start monitoring based on your above settings: record
immediately, only record on the scheduled time, or record by an input trigger.. –OR-
•
Select SAVE to save the monitoring settings. Then press the REC button on the Remote
Control at any time to start your monitoring settings.
Also see 6.4 Monitoring of the web-based configuration which provides more information and
features of the monitoring settings.
OSD Menu Configurations
4
Figure 4-25
