6.4 Monitoring

You can start recording manually, by schedule or by input trigger.
[Manual] Manually activates recording and I/O monitoring. Select one of the following options
and then click the Start button.
Select all: Manually starts recording and I/O monitoring as well.
Camera 1 - Camera 4: Manually starts recording. Select the desired camera(s) and the
recording mode for recording.
Input: Manually starts I/O monitoring. When the input is triggered, its associated camera
and output will also be activated for recording and alerting. For input settings, see 6.2.1
I/O Control.
[Schedule] The system starts recording and I/O monitoring based on the schedule you set.
For schedule settings, see 6.5 Recording Schedule.
[Start monitoring by Input X] Starts monitoring by the assigned input. When the assigned input is
triggered, the system will respond based on your recording or I/O monitoring settings in above Manual
or Schedule options.
[Stop monitoring by Input X] Stops monitoring by the assigned input. When the assigned input is
triggered, the system will stop monitoring.
Remove HDD: When the monitoring is stopped by the input trigger, the storage device
will also be removed from the system.
[Camera Status Icon]
: Manual recording
: On standby
Figure 6-26
: Schedule recording
: Enabled for motion detection and input trigger
