RRP3.15 ACTUATOR NO PAPER (PL3.3.20)
[Removal]
1) Remove PAPER FEEDER. (RRP3.3)
2) Remove PAPER FEEDER CHUTE. (RRP3.1)
3) Remove PAPER PICKUP ASSEMBLY. (RRP3.7)
4) Remove the two screws (silver, tap, 8mm) that fix GUIDE PAPER to PAPER PICKUP
ASSEMBLY.
5) Turn over PAPER PICKUP ASSEMBLY.
6) Release the hook that fixes ACTUATOR NO PAPER to PAPER PICKUP ASSEMBLY.
7) Pull out ACTUATOR NO PAPER a little, then shift the thin section of the shaft from the hole
to the slot side.
8) Remove ACTUATOR NO PAPER out of the slot of PAPER PICKUP ASSEMBLY while moving
the hook side of ACTUATOR NO PAPER forward.
[Replacement]
1) Insert ACTUATOR NO PAPER into the slot of PAPER PICKUP ASSEMBLY.
2) Shift the thin section of the shaft of ACTUATOR NO PAPER from the slot of PAPER PICKUP
ASSEMBLY to the installation hole of ACTUATOR NO PAPER.
3) Insert the boss of ACTUATOR NO PAPER into the hole of PAPER PICKUP ASSEMBLY, then
fix the hook and attach it.
4) Match the boss of ACTUATOR NO PAPER to the hole of PAPER PICKUP ASSEMBLY, fix
GUIDE PAPER using the screw (silver, tap, 8mm)
5) Attach PAPER PICKUP ASSEMBLY. (RRP3.7)
6) Attach PAPER FEEDER CHUTE. (RRP3.1)
7) Attach PAPER FEEDER. (RRP3.3)
