Chapter 3 Removal and Replacement Procedures (RRPs)
PRINTER RRP FLOW
This flow shows the removing procedures of the following parts.
(500 SHEET PAPER TRAY Reration)
RETARD ASSY, SEPARATOR ROLLER, SEPARATOR ROLLER CLUTCH
(PAPER FEEDER Reration)
PAPER FEEDER CHUTE, PAPER TRAY COVER, PAPER FEEDER
PAPER PICKUP ASSEMBLY, PAPER FEED ROLLER
Removing 500 SHEET PAPER TRAY Removing TOP COVER
RETARD ASSY (RRP2.2)
Removing TONER CARTRIDGE (Y), (M), (C), (K)
SEPARATOR ROLLER,
Opening FRONT COVER
SEPARATOR ROLLER CLUTCH (RRP2.1)
Opening IMAGING DRUM COVER
PAPER FEEDER CHUTE (RRP3.1)
Removing IMAGING DRUM
PAPER FEED ROLLER (RRP3.14)
TOP COVER FRAME (RRP1.1)
PAPER TRAY COVER (RRP3.2)
RIGHT SIDE COVER (RRP1.7)
LEFT SIDE COVER (RRP1.12)
COVER ASSY REAR (RRP1.5)
REGISTRATION ASSEMBLY (RRP4.6)
REGISTRATION CHUTE ASSEMBLY (RRP4.3)
HIGH VOLTAGE POWER SUPPLY (HVPS) (RRP9.9)
SENSOR HUM (RRP9.8)
Removing 500 SHEET PAPER TRAY
PAPER FEEDER (RRP3.3) PAPER FEEDER (RRP3.3)
PAPER PICKUP ASSEMBLY (RRP3.7)
3 - 7
