GE Security Concord 4 Installation Manual page 180

166 Concord 4
Installation Manual
Table 27. System event trigger numbers
System event
AVM is interactive (audio session in
progress)
Fail-to-communicate (panel can't call CS or
pager)
AVM trip (edge)
Keychain touchpad star button-press
Smoke power (for resetting 4-wire smoke
detectors)
Exterior siren
Interior siren
AVM trip (pulse)
State of system status
Tamper condition
Closing report sent
Arming to level 1
Group XX in alarm
Sensor XX in alarm
Sensor XX open
Table 28. Sensor group event trigger numbers
Sensor group
Group 00 in alarm
Group 01 in alarm
Group 02 in alarm
Group 03 in alarm
Group 04 in alarm
Group 05 in alarm
Group 06 in alarm
Group 07 in alarm
Group 08 in alarm
Description
When the central station operator begins listening or
talking to the premises.
When the fail-to-communicate output is activated.
When an AVM alarm occurs, output is activated
momentarily.
When the star button on a keychain touchpad is pressed. 014
Deactivated when hardwire smoke detectors need to be
reset.
Activated for police or fire alarms.
Activation follows all system noises
When an AVM alarm occurs, output is deactivated for 10
ms
Follows the state of system status (ready or trouble).
When any tamper is tripped
When a closing report has been successfully transmitted
to the central station.
When the system is disarmed.
When any sensor in group XX goes into alarm
When sensor number XX goes into alarm
When sensor number XX is opened
Trigger no. Sensor group
064 Group 17 in alarm
065 Group 18 in alarm
066 Group 19 in alarm
067 Group 20 in alarm
068 Group 21 in alarm
069 Group 22 in alarm
070 Group 23 in alarm
071 Group 24 in alarm
072 Group 25 in alarm
Trigger no.
011
012
013
015
016
017
018
019
020
021
022
Trigger no.
081
082
083
084
085
086
087
088
089
