GE
Security
Simon XT V2 Installation Guide
Content
Contact information
For contact information see our Web site:
www.gesecurity.com.
Description
This is the Installation Guide for the Simon XT control panel
(model 600-1054-95R-V2).
The system can monitor up to 40 sensors including:
•
Door/Window sensor (60-670)
•
Indoor motion sensor (60-639)
•
Outdoor motion sensor (60-639)
•
Remote handheld touchpad (60-671)
Contact your GE representative for a more complete list.
Caution:
Do not use outdoor motion sensors for intrusion
protection
Table 1 below describes the recommended sensor groups.
Table 1: Recommended sensor groups
Device
Indoor motion sensor
Outdoor motion sensor
Entry/exit door
Interior door
Window sensor
Smoke sensor
CO alarm
Freeze sensor
Water sensor
a.
Not certified as a primary protection circuit for UL-listed
systems and is for supplementary use only.
b.
Has not been investigated by UL.
c.
Required for UL-listed residential fire alarm applications.
Installation
Tabs at the top of the panel secure and release the front
cover and the chassis. The plastic hinges on the panel
bottom allow the cover and chassis to swing down and out
of the way.
To mount the panel on a wall:
1.
Choose a panel location.
2.
Run all necessary power, phone, siren, and hardwired
contact wires to the desired panel location.
© 2010 GE Security, Inc.
Recommended sensor group
17
a
25 (chime only group)
b
10
14
13
26
c
01
01
01
34
b
29
b
38
b
01
P/N 466-2375 • REV A • ISS 24FEB10
