6.4
Drive Power Connector
Maximum rating via Drive Power Connector:
• +5V/2A
• +12V/2A
Copyright © 2014 congatec AG
12/19-24 V DC
12/19-24 V DC
Power
Data
Data
IGX1m02
41/134
