3.4

conga-IGX Variants

conga-IGX/210HA
conga-IGX/217GA
conga-IGX/420CA
Note
1. Maximum supported memory clock.
2. For all conga-IGX variants, DDR3-1333 (CL9) or DDR3-1600 (CL11) memory modules can be installed.
3. Up to 16GB SDRAM (unbuffered, no ECC) is possible.
4. Two memory sockets available (single channel mode). Compliant with JEDEC DDR3 1.5V, DDR3L 1.35V and DDR3U 1.25V
Copyright © 2014 congatec AG
Processor (SoC) Graphics
GX-210HA
Dual Core 1.0 GHz / 9W
Radeon HD 8210E
64kB L1 Cache per Core 300 MHz
1MB L2 Cache shared
GX-217GA
Dual Core 1.65 GHz / 15W Radeon HD 8280E
64kB L1 Cache per Core 450 MHz
1MB L2 Cache shared
GX-420CA
Quad Core 2.00 GHz / 25W Radeon HD 8400E
64kB L1 Cache per Core 600 MHz
2MB L2 Cache shared
Memory
DDR3 / 1333
(see note below)
DDR3 / 1600
(see note below)
DDR3 / 1600
(see note below)
IGX1m02
Display Options
1 x DVI-I;
1 x DP V1.2;
1 x LVDS 24Bit Dual Ch.;
max. 2 independent displays
(DVI-I & DP or DVI & LVDS)
