DC Plug
Power_Switch
Reset_Switch
Power_Switch
LVDS operating voltage jumper selector:
Reserved
Pin
1
2 Power
3
2
12 V 3-pin mode
1
Drive Power 1 = Vcc 5 V max. 2 A
1
Copyright © 2014 congatec AG
1 = + DC
2 = GND
12 V max. 60 Watt
1
19-24 V max. 100 Watt
2
Plug: 2.5 / 5.5 / 11 mm
Signal
VCC 5V
Power LVDS
1 = GND
2 = GND
VCC 3.3V
4
3 = + DC 12 / 19-24 V
3
4 = + DC 12 / 19-24 V
2 = GND
3 = GND
4 = +12 V max. 2 A
Jumper Settings
LVDS BL Control Settings
Analog PWM
(default)
LVDS Supply Settings
VCC 3.3 V VCC 5 V
(default)
BIOS Recovery Settings
Normal Operation (default)
BIOS Recovery / Reset to Defaults
System Power On Settings
Normal Operation (default)
Always on
