LVDS Connector details

LVDS Connector: Hirose DF13-40 (or compatible).
PIN SIGNAL
2 Ground
LVDS_H3+ (EVEN_3+)
4
LVDS_H3- (EVEN_3-)
6
8 Ground
LVDS_H2+ (EVEN_2+)
10
LVDS_H2- (EVEN_2-)
12
14 Ground
LVDS_H1+ (EVEN_1+)
16
LVDS_H1- (EVEN_1-)
18
20 Ground
LVDS_H0+ (EVEN_0+)
22
LVDS_H0- (EVEN_0-)
24
26 Ground
LVDS_CLK_H+ (CLK_EVEN_+)
28
LVDS_CLK_H- (CLK_EVEN_-)
30
32 Ground
34 DDC-Data
36 LCD-Power (see note below)
38 Ground
LCD_Power_Enable
40
Note
Selectable via jumper.
Caution
Maximum load: 1A per pin.
el 1 = HDD_LED+ 6 = Power_Switch
2 = Power_LED+ 7 = Reset_Switch
3 = HDD_LED- 8 = Power_Switch
1
4 = Power_LED- 9 = Reserved
2
5 = Reset_Switch
