4
Heatsink/Heatpipe Installation Notes
(SATA connectors)
Due to the required dimensions of the 15W passive heatsink with heatpipes, the onboard SATA ports are covered when the device is installed.
Note
SATA cables with angle connectors can be used when utilizing a passive heatsink with heatpipes, but they must be installed before mounting
the heatsink with heatpipes.
Copyright © 2014 congatec AG
IGX1m02
22/134
