5.5

LVDS Timing & Screen Resolution

There are 9 default LVDS settings available:

• BIOS Setup Advanced - LVDS Config Select

Note

Option 10 (LVDS adjusted Parameters) becomes visible after once running the "LVDS Tool" for implementing customized LVDS settings.

"Non-EDID Support" must be set to <Enabled> for standard LVDS displays without DDC (EDID) interface.

IGX1m02

28/134
