24.3.2

Inverter Cable Plan

conga-IGX
Inverter-Connector JST PHR-8
Signal Symbol
Ground GND
Ground GND
Backlight Brightness CTRL tbd
Power 5V VCC
Power 5V VCC
Backlight On/Off Control BL On/Off
+12V
Power 12V
+12V
Power 12V
24.3.3 Inverter Pinout Green C&C GH053A
Pin Symbol
BRT_ADJ
2
1,3,5,6,8,9
GND
BL ON/OFF
4
7 N.C
10,11,12 DC-IN(Vin)
Note: Mirrored Pinout
Copyright © 2014 congatec AG
Pin
1
2
3
4
5
6
7
8
Remark
0 ~ 5V
GND
CCFL Drive SIGNAL(Active HIGHT)
DC INPUT Power (12V)
Green C&C GH053A
53261-1290 (Molex) or equivalent
Pin Symbol
◄▪▪▪▪▪►
7 (6) GND
◄▪▪▪▪▪►
5 (8) GND
BRT_Adj
◄▪▪▪▪▪►
11 (2)
◄▪▪▪▪▪► 9 (4) BL On/Off
◄▪▪▪▪▪►
3 (10) DC-In / 12V
◄▪▪▪▪▪►
1 (12) DC-In / 12V
Pinout analog connector CN1 (mirrored to inverter spec, inverter
pinout in brackets)
IGX1m02 122/134
