24.1

AUO_G0121SN01 LVDS Cable Pinout

conga-IGX
LVDS Connector Hirose DF13-40, straight, SMT
Signal Symbol
Ground GND
Ground GND
LVDS_Out3+ (ODD_3+) LO3+
LVDS_Out7+ (EVEN_3+) LO7+
LVDS_Out3- (ODD_3-) LO3-
LVDS_Out7- (EVEN_3-) LO7-
Ground GND
Ground GND
LVDS_Out2+ (ODD_2+) LO2+
LVDS_Out6+ (EVEN_2+) LO6+
LVDS_Out2- (ODD_2-) LO2-
LVDS_Out6- (EVEN_2-) LO6-
Ground GND
Ground GND
LVDS_Out1+ (ODD_1+) LO1+
LVDS_Out5+ (EVEN_1+) LO5+
LVDS_Out1- (ODD_1-) LO1-
LVDS_Out5- (EVEN_1-) LO5-
Ground GND
Ground GND
LVDS_Out0+ (ODD_0+) LO0+
LVDS_Out4+ (EVEN_0+) LO4+
LVDS_Out0- (ODD_0-) LO0-
LVDS_Out4- (EVEN_0-) LO4-
Ground GND
Ground GND
LVDS_CLK1+ (CLK_ODD+) CLK1+
LVDS_CLK2+ (CLK_EVEN+) CLK2+
LVDS_CLK1- (CLK_ODD-)
CLK1-
LVDS_CLK2- (CLK_EVEN-)
CLK2-
Ground GND
Ground GND
DDC-Clock DDCCLK
DDC-Data DDCDATA
+3.3V / +5V
LCD-Power 1)
+3.3V / +5V
LCD-Power 1)
+3.3V / +5V
LCD-Power 1)
Ground GND
Ground GND
LCD_PowerOn LCD_On
Copyright © 2014 congatec AG
AUO- G0121SN01
LVDS-Connector JAE FI-S20S or compatible
Pin Pin Symbol
1
2
3
4
5
6
◄▪▪▪▪▪►
7 3 GND
◄▪▪▪▪▪►
8 4 GND
9 ◄▪▪▪▪▪► RxIN2+
12
10
◄▪▪▪▪▪►
11 11 RxIN2-
12
13
◄▪▪▪▪▪►
14 7 GND
◄▪▪▪▪▪► 9 RxIN1+
15
16
◄▪▪▪▪▪►
17 8 RxIN1-
18
19
◄▪▪▪▪▪►
20 10 GND
◄▪▪▪▪▪► RxIN0+
21 6
22
◄▪▪▪▪▪►
23 5 RxIN0-
24
25
◄▪▪▪▪▪►
26 13 GND
◄▪▪▪▪▪► CKIN+
27 15
28
29 ◄▪▪▪▪▪►
14 CKIN-
30
◄▪▪▪▪▪►
31 16 GND
32
33
34
◄▪▪▪▪▪►
35 1 VDD
◄▪▪▪▪▪►
36 2 VDD
37
38
39
40
24.1.1

Panel Pinout AUO G0121SN01

Pin Signal Name
1 VDD
3 GND
5 RxIN0-
7 GND
9 RxIN1+
11 RxIN2-
13 GND
CKIN+
15
17 NC/GND
19 (Note1)
NC/GND
Note1: Pin19 can be used for plugging "reverse scan" function.
IGX1m02
Pin Signal Name
2 VDD
4 GND
RxIN0+
6
8 RxIN1-
10 GND
RxIN2+
12
14 CKIN-
16 GND
18 NC/GND
20 NC/GND
117/134
