Display Options

5.1

Basic Display Features

The graphics engine of the conga-IGX supports maximum 2 independent displays, following combinations are possible:
Config#
DisplayPort V1.2
Maximum 3840 x 2160
1 X
2 X
3
4
Note
Via DVI-I to VGA converter
Simultaneous use of DisplayPort and onboard LVDS is not possible; the appropriate G-series video channel can only be used exclusively for
DisplayPort (=LVDS disabled in BIOS Setup) or for LVDS (=LVDS enabled in BIOS Setup).
The DisplayPort output can be converted to a HDMI output, VGA output or (second) DVI output (appropriate converter required).
Windows 8 mode (=Secure Boot enabled) & LVDS support should only be used for BIOS revision R1.1.0, otherwise any graphics output may
be disabled. In case this happens, Setup Defaults should be enabled (see section Miscellaneous - BIOS/CMOS Reset).
Copyright © 2014 congatec AG
LVDS DVI-I (digital)
Maximum 1920 x 1200 Maximum 1920 x 1200
X
X X
X
IGX1m02
DVI-I (analog VGA)
Maximum 1920 x 1200
X (see note below)
X (see note below)
