24.1.2

Inverter Cable Plan

conga-IGX
Inverter-Connector JST PHR-8
Signal Symbol
Ground GND
Ground GND
Backlight Brightness CTRL tbd
Power 5V VCC
Power 5V VCC
Backlight On/Off Control BL On/Off
+12V
Power 12V
+12V
Power 12V
24.1.3 Inverter Pinout Green C&C GH093A
Signal Symbol
1,2 DC-IN(Vin)
3,4 GND
BL ON/OFF
5
BRT_ADJ
6
Copyright © 2014 congatec AG
Pin
1
2
3
4
5
6
7
8
Remark
DC INPUT Power (12V)
GND
CCFL Drive SIGNAL(Active HIGHT)
0 ~ 5V
Green C&C GH093A
20037WR-06A00(P) (YEONHO) / EQUIVALENT
Pin Symbol
◄▪▪▪▪▪►
3 GND
◄▪▪▪▪▪►
4 GND
BRT_Adj
◄▪▪▪▪▪►
6
◄▪▪▪▪▪► BL On/Off
5
◄▪▪▪▪▪►
1 DC-In / 12V
◄▪▪▪▪▪►
2 DC-In / 12V
IGX1m02 118/134
