Internal Usb 3.0 Ports - Congatec conga-IGX User Manual

7.3

Internal USB 3.0 Ports

Pin Signal
1 VCC AUX
USB3_RX positive (P2)
3
USB3_TX negative (P2)
5
7 GND
9
Data positive (P2)
11 Data positive (P3)
13 GND
USB3_TX negative (P3)
15
USB3_RX positive (P3)
17
19
VCC AUX
Copyright © 2014 congatec AG
Pin Signal
USB3_RX negative (P2)
2
4 GND
USB3_TX positive (P2)
6
8 Data negative (P2)
10 FP Detect
12 Data negative (P3)
USB3_TX positive (P3)
14
16 GND
USB3_RX negative (P3)
18
20 <Key>
Front Panel
1
2
Fan 1 (CPU)
Fan 2 (Chassis)
1
IGX1m02
COM 2
DisplayPort
LAN
2x USB 2.0
LAN
2x USB 2.0
Mouse
Keyboard
1 = HDD_LED+ 6 = Power_Switch
2 = Power_LED+ 7 = Reset_Switch
3 = HDD_LED- 8 = Power_Switch
4 = Power_LED- 9 = Reserved
5 = Reset_Switch
1 = GND
2 = 12 V PWM mode, 4..12 V 3-pin mode
3 = Sense
4 = PWM
LVDS
CPU
2x USB 3.0
FAN 1
SATA0 SAT
Front Audio
mini PCIe
SPDIF
PCIe X4
DC Plug
1
2
Power
2 4
1 3
45/134
