ADSP-TS201S

ORDERING GUIDE

Temperature
Model Range
ADSP-TS201SABP-060 –40°C to +85°C
ADSP-TS201SABP-050 –40°C to +85°C
ADSP-TS201SYBP-050 –40°C to +105°C 500 MHz
3
ADSP-TS201SABPZ060 –40°C to +85°C
3
ADSP-TS201SABPZ050 –40°C to +85°C
3
ADSP-TS201SYBPZ050 –40°C to +105°C 500 MHz
1
Represents case temperature.
2
The instruction rate is the same as the internal processor core clock (CCLK) rate.
3
Z = Pb-free part.
Instruction On-Chip
1 2
Rate DRAM
600 MHz 24M bit
500 MHz 24M bit
24M bit
600 MHz 24M bit
500 MHz 24M bit
24M bit
Rev. C | Page 46 of 48 | December 2006

Operating Voltage

1.20 V , 2.5 V , 1.6 V
DD DD_IO DD_DRAM
1.05 V , 2.5 V , 1.5 V
DD DD_IO DD_DRAM
1.05 V , 2.5 V , 1.5 V
DD DD_IO DD_DRAM
1.20 V , 2.5 V , 1.6 V
DD DD_IO DD_DRAM
1.05 V , 2.5 V , 1.5 V
DD DD_IO DD_DRAM
1.05 V , 2.5 V , 1.5 V
DD DD_IO DD_DRAM
Package Package
Option Description
BP-576 576-Ball BGA_ED
BP-576 576-Ball BGA_ED
BP-576 576-Ball BGA_ED
BP-576 576-Ball BGA_ED
BP-576 576-Ball BGA_ED
BP-576 576-Ball BGA_ED
