576-BALL BGA_ED PIN CONFIGURATIONS

Figure 46 shows a summary of pin configurations for the
576-ball BGA_ED package and
assignments.
2
1
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
T
U
V
W
Y
AA
AB
AC
AD
1
For a more detailed pin summary diagram, see the EE-179: ADSP-TS201S System Design Guidelines on the Analog Devices website (www.analog.com).
Table 35 lists the signal-to-ball
4 6 8
10 12
5 7 11
3 9
TOP VIEW
Figure 46. 576-Ball BGA_ED Pin Configurations
Rev. C | Page 41 of 48 | December 2006
14 16 20 22
18
15 19 21
13 17
1
(Top View, Summary)
ADSP-TS201S
24
23
KEY:
SIGNAL
V
DD
V
DD_IO
V
DD_DRAM
V
DD_A
V
REF
V
SS
NO CONNECT
