STRAP PIN FUNCTION DESCRIPTIONS

Some pins have alternate functions at reset. Strap options set
DSP operating modes. During reset, the DSP samples the strap
option pins. Strap pins have an internal pull-up or pull-down
for the default value. If a strap pin is not connected to an over-
driving external pull-up, pull-down, or logic load, the DSP
samples the default value during reset. If strap pins are
Table 16. Pin Definitions—I/O Strap Pins
Type (at
Signal Reset)
EBOOT I
(pd_0)
IRQEN I
(pd)
LINK_DWIDTH I
(pd)
SYS_REG_WE I
(pd_0)
TM1 I
(pu)
TM2 I
(pu)
TM3 I
(pu)
I = input; A = asynchronous; O = output; OD = open-drain output; T = three-state; P = power supply; G = ground; pd = internal pull-down
Ω
5 k ; pu = internal pull-up 5 k
Ω
pull-up 500 on DSP ID = 0; pd_m = internal pull-down 5 k
Ω
= internal pull-up 40 k . For more pull-down and pull-up information, see
When default configuration is used, no external resistor is
needed on the strap pins. To apply other configurations, a
500 Ω resistor connected to V
external pull-downs, do not strap these pins directly to V
strap pins require 500 Ω resistor straps.
All strap pins are sampled on the rising edge of RST_IN (deas-
sertion edge). Each pin latches the strapped pin state (state of
the strap pin at the rising edge of RST_IN). Shortly after deas-
sertion of RST_IN, these pins are reconfigured to their normal
functionality.
These strap pins have an internal pull-down resistor, pull-up
resistor, or no-resistor (three-state) on each pin. The resistor
type, which is connected to the I/O pad, depends on whether
RST_IN is active (low) or if RST_IN is deasserted (high).
Table 17 shows the resistors that are enabled during active reset
and during normal operation.
On Pin ...
BMS
BM
TMR0E
BUSLOCK
L1BCMPO
L2BCMPO
L3BCMPO
Ω
; pd_0 = internal pull-down 5 k
is required. If providing
DD_IO
SS
Rev. C | Page 20 of 48 | December 2006
connected to logic inputs, a stronger external pull-up or pull-
down may be required to ensure default value depending on
leakage and/or low level input current of the logic load. To set a
mode other than the default mode, connect the strap pin to a
sufficiently stronger external pull-up or pull-down.
lists and describes each of the DSP's strap pins.
Description
EPROM Boot.
0 = boot from EPROM immediately after reset (default)
1 = idle after reset and wait for an external device to boot DSP
through the external port or a link port
Interrupt Enable.
0 = disable and set IRQ3–0 interrupts to edge-sensitive after
reset (default)
1 = enable and set IRQ3–0 interrupts to level-sensitive
immediately after reset
Link Port Input Default Data Width.
0 = 1-bit (default)
1 = 4-bit
SYSCON and SDRCON Write Enable.
0 = one-time writable after reset (default)
1 = always writable
Test Mode 1. Do not overdrive default value during reset.
Test Mode 2. Do not overdrive default value during reset.
Test Mode 3. Do not overdrive default value during reset.
Ω
on DSP ID = 0; pu_0 = internal pull-up 5 k
Ω
on DSP bus master; pu_m = internal pull-up 5 k
Electrical Characteristics on Page
Table 17. Strap Pin Internal Resistors—Active Reset
(RST_IN = 0) vs. Normal Operation (RST_IN = 1)
Pin
; the
BMS
BM
TMR0E
BUSLOCK
L1BCMPO
L2BCMPO
L3BCMPO
pd = internal pull-down 5 k
pd_0 = internal pull-down 5 k
pu_0 = internal pull-up 5 k
Ω
on DSP ID = 0; pu_od_0 = internal
Ω
on DSP bus master; pu_ad
22.
RST_IN = 0 RST_IN = 1
(pd_0) (pu_0)
(pd) Driven
(pd) Driven
(pd_0) (pu_0)
(pu) Driven
(pu) Driven
(pu) Driven
Ω
; pu = internal pull-up 5 k
Ω
on DSP ID = 0;
Ω
on DSP ID = 0
Table 16
Ω
;
